Bently Nevada 330101-00-20-15-02-05 8 mm Proximity Probe and CSA / ATEX / IECEx Certification
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
The Bently Nevada 330101-00-20-15-02-05 is a high-performance, non-contacting displacement sensor designed for critical rotating machinery. As part of the gold-standard 3300 XL series, this 8mm probe delivers precision vibration and position data in environments where accuracy isn't optional—it's a safety requirement.
Ordering Information Breakdown
Engineers and procurement teams often look for specific ordering information strings. Here is the configuration breakdown for this exact part number:
- Model No: 330101 (3/8-24 UNF thread, no armor)
- Unthreaded Length (-00): 0.0 inches - Perfect for flush-mount or thin-bracket installations
- Case Length (-20): 2.0 inches (50.8 mm) - Standard depth for most bearing housings
- Total System Length (-15): 1.5 Meters (approximately 4.9 feet)
- Connector Type (-02): Miniature coaxial ClickLoc™ connector - Gold-plated for zero-signal loss
- Approval Option (-05): Multi-certified for hazardous areas (CSA, ATEX, IECEx)
| Item | Specification |
|---|---|
| Probe Diameter | 8 mm |
| Thread | 3/8-24 UNF |
| Case Length | 2.0 in (minimum) |
| Unthreaded Length | 0.0 in |
| Cable Length | 1.5 m (4.9 ft) |
| Connector Type | Miniature coaxial ClickLoc |
| Certifications | CSA / ATEX / IECEx |
| Net Weight | 0.06 kg |
| Probe Case Thread | 3/8-24 0.563 in |
Core Technical Capabilities
- API 670 Compliant: Designed for seamless integration with 3300 XL Proximitor® Sensors, ensuring total interchangeability without recalibrating individual components
- PPS Probe Tip: The tip is molded from high-temperature Polyphenylene Sulfide (PPS), resisting oil, water, and caustic chemical penetration
- ClickLoc™ Connectivity: Features the patented locking mechanism that prevents accidental disconnects caused by machine vibration
- Linear Range: Provides a standard 80 mil (2.0 mm) linear range, ideal for radial vibration, axial thrust, and Keyphasor applications
Application Benefits
The 330101-00-20-15-02-05 is frequently sourced for gas and steam turbine retrofits where the 3/8-24 thread is the standard mounting interface. The "05" approval code makes it a universal spare for global fleets, meeting both North American (CSA) and European (ATEX) safety standards in one part number.
Installation Guidelines
- Gap Setting: Aim for the center of the linear range (typically -10 Vdc) using a digital voltmeter during installation to ensure maximum dynamic range
- Cable Routing: Since this is the "without armor" version, ensure cable runs are protected by conduit or internal housing to prevent mechanical shearing
- Interchangeability: This 1.5m probe is designed to work with a 3300 XL Proximitor sensor specifically tuned for a 5-meter or 9-meter system. Check your total system length before commissioning
