Bently Nevada 330130-040-00-05 3300 XL Standard Extension Cable with 4.0 Meters Length and Gold-plated ClickLoc™ Connectors for Hazardous Areas
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
Bently Nevada 330130-040-00-05 Bently Nevada 3300 XL Standard Extension Cable
Product Overview
| Parameter | Specification Details |
|---|---|
| Part Number | 330130-040-00-05 |
| System Series | 3300 XL 8mm Proximity Transducer System |
| Component Type | Standard Extension Cable |
| Cable Length | 4.0 Meters (Approx. 13.1 feet) |
| Cable Material | 75Ω triaxial, FEP (Fluorinated Ethylene Propylene) insulated |
| Connector Type | Gold-plated ClickLoc™ coaxial connectors (finger-tighten) |
| Agency Approval | 05 (Multiple Approvals): Includes CSA, ATEX, and IECEx for hazardous areas |
| Connector Option | 00 (Standard): Without connector protector |
| Operating Temperature | -51°C to +177°C (-60°F to +350°F) |
| Interchangeability | Fully compatible with 3300 XL 8mm probes and Proximitors |
| Primary Application | Monitoring radial vibration, axial position, and Keyphasor signals |
Contact Information
Key Applications
- Critical Machinery Protection: Used on high-speed rotating equipment like steam turbines, gas turbines, centrifugal compressors, and large pumps.
- Comprehensive Signal Monitoring: Handles radial vibration, axial thrust position, shaft eccentricity, and Keyphasor speed signals. Mainly used to keep machine condition under control and avoid serious faults.
- Hazardous Area Deployment: With Option 05 (agency approval), the 330130-040-00-05 can be used in explosive environments. Common approvals include ATEX, IECEx, and CSA.
- API 670 Compliance: Often used as part of Machinery Protection Systems (MPS) that follow API 670 requirements for industrial reliability and monitoring accuracy.
Technical Features
- Signal Integrity: The 330130-040-00-05 3300 XL Extension Cable uses 75Ω triaxial shielding with FEP insulation. It helps reduce EMI and keeps signal stable over the 4.0-meter cable length.
- ClickLoc™ Connection: Uses gold-plated ClickLoc™ connectors. It locks with a simple “click” and finger-tight fit, so no tools are needed. Also helps reduce loosening in vibration environments.
- Environmental resistance: Built for harsh industrial conditions. Works from -51°C to +177°C (-60°F to +350°F) and resists oil, chemicals, and moisture.
- System compatibility: Fully compatible with Bently Nevada 3300 XL 8mm system, including probes and Proximitor sensors. Can be replaced directly in the field without re-calibration, so downtime is reduced.
- Certification (Option 05): Option 05 provides multi-agency approvals. It supports global compliance for different regions and safety requirements.
Frequently Asked Questions
Q1: What is 330130-040-00-05 exactly?
A: The 330130-040-00-05 is a 3300 XL Extension Cable.
“040” means 4.0 meters cable length.
“00” is the standard version.
“05” is the agency approval option, used for hazardous area compliance like ATEX, IECEx, and CSA.
“040” means 4.0 meters cable length.
“00” is the standard version.
“05” is the agency approval option, used for hazardous area compliance like ATEX, IECEx, and CSA.
Q2: Is 330130-040-00-05 compatible with older systems?
A: Yes, it can work with older 3300 XL 8mm systems and also some non-XL 5mm/8mm setups. It’s generally interchangeable as long as the total system length stays correct and the setup is matched.
Q3: What temperature range can 330130-040-00-05 handle?
A: The 330130-040-00-05 works from -51°C to +177°C (-60°F to +350°F). The FEP insulation helps it handle heat, moisture, and oil exposure in industrial environments.
Q4: What is special about the ClickLoc™ connector on the 330130-040-00-05?
A: 330130-040-00-05 uses ClickLoc™ connectors with gold-plated contacts. You just tighten by hand until it clicks. It helps avoid loosening from vibration and keeps the connection stable without tools.
Q5: What is the cable impedance of 330130-040-00-05?
A: It is a 75Ω triaxial cable. This helps keep signal stable between the probe and the Bently Nevada 3300 XL Proximitor Sensor system, especially for vibration and position signals.
Q6: Does the 330130-040-00-05 require any special tools for installation?
A: No, no special tools are needed for the 330130-040-00-05. The ClickLoc™ connectors are meant to be tightened by hand. Usually it’s just plug and click. If needed, you can use connector silicone tape or optional connector protectors (if included or purchased separately) to help isolate the connection from the machine housing and avoid ground loop issues in the system.
Compatible Part Numbers
| 330851-06-000-070-50-00-05 | 330103-00-05-10-02-CN |
| 330101-00-08-10-02-00 | 330106-05-30-20-02-CN |
| RS900106-05-30-05-02-00 | 330130-070-00-CN |
| 330704-000-050-10-02-00 | 170180-01-00 |
| 330104-00-02-10-02-00 | 330130-075-00-CN |
| 330730-080-12-CN | 330103-08-15-10-02-00 |
| 31000 SC115582-1 | 991-06-70-01-00 |
| 330100-50-05 | 330103-00-08-05-02-CN |
| 330705-02-18-90-02-00 | 330980-71-CN |
| 76683-50 | 330171-00-08-10-02-00 |
| 330101-00-40-10-02-00-CN | 330171-08-24-10-02-00 |
| 330910-05-11-10-02-00 | 330173-07-11-10-02-00 |
| 130118-0050-02 | 330103-00-04-05-02-CN |
| 330101-XX-XX-10-02-CN | 330103-00-05-15-02-CN |
| 330103-00-05-10-01-00 | 330103-00-06-05-02-CN |
| 330103-02-06-05-02-00 | 330104-00-13-10-02-00 |
| 330103-05-12-10-01-00 | 330930-060-01-CN |
| 330101-24-35-10-02-00 | 330102-00-40-10-02-00 |
| 84661-6 | 330101-23-38-10-02-00 |
| 330103-00-04-15-02-CN | 9200-02-01-10-00 |
