Bently Nevada 330104-00-11-10-02-05 3300 XL 8 mm Proximity Probe with Stainless Steel Armor and API 670 Compliance
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
Bently Nevada 330104-00-11-10-02-05 3300 XL 8 mm Proximity Probe
Product Overview
| Category | Specification Item | Official Value / Standard Data |
|---|---|---|
| Ordering | Model Number | 330104 (3300 XL 8 mm Proximity Probe, M10 x 1 thread, with armor) |
| Ordering | Unthreaded Length (00) | 0 mm |
| Ordering | Overall Case Length (11) | 110 mm |
| Ordering | Total Cable Length (10) | 1.0 metre (3.3 feet) |
| Ordering | Connector Type (02) | ClickLoc Miniature Coaxial |
| Ordering | Agency Approval (05) | Multiple Approvals (ATEX, IECEx, CSA) |
| Mechanical | Probe Tip Diameter | 8 mm |
| Mechanical | Thread Pitch | M10 × 1 |
| Mechanical | Cable Protection | Stainless steel armor |
| Mechanical | Tip Material | Polyphenylene sulfide (PPS) |
| Mechanical | Case Material | AISI 304 stainless steel |
| Mechanical | Max Tensile Strength | 330 N (75 lbf) |
| Electrical | Linear Range | 2.0 mm (80 mils) |
| Electrical | Scale Factor (ASF/ISF) | 7.87 V/mm (200 mV/mil) |
| Electrical | Linearity Error (DSL) | ≤ ±0.025 mm (≤ ±1 mil) |
| Electrical | Frequency Response | 0 to 6.5 kHz |
| Electrical | Target Material | AISI 4140 Steel |
| Electrical | Supply Voltage | -17.5 Vdc to -26 Vdc |
| Electrical | Center Conductor DCR |
7.59 Ω ± 0.50 Ω |
| Environmental | Operating Temperature | -35°C to +177°C (-31°F to +350°F) |
Contact Us for Pricing or Technical Support
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
Key Features
- Integrated Stainless Steel Armor: Formidable mechanical protection via flexible stainless steel conduit, safeguarding the coaxial cable from abrasive bearing environments and sharp metal debris.
- M10 ×1 Metric Thread Configuration: Standardized metric housing with 110 mm total case length and 0 mm unthreaded portion, optimized for direct-insertion tapped holes in industrial machinery housings.
- ClickLoc Miniature Coaxial Connector: Gold-plated, corrosion-resistant connector with self-locking mechanisms to eliminate signal intermittent failures caused by machine vibration.
- Polyphenylene Sulfide (PPS) Tip: High-strength, chemical-resistant engineering plastic tip capable of enduring continuous exposure to corrosive hot lubricating fluids.
- Non-Contact Eddy Current Technology: High-precision, zero-wear sensing technology tailored for high-speed industrial rotating machinery asset protection.
- Wide Linear Range: Formidable 2.0 mm (80 mils) linear measurement span starting with a nominal 0.25 mm (10 mils) initial clearance gap.
- High Scale Factor Accuracy: Delivers standard 7.87 V/mm (200 mV/mil) sensitivity with strict incremental scale factor deviations.
- High-Frequency Response: Covers 0 Hz to 6.5 kHz frequency band, capable of tracking sub-synchronous, synchronous, and high-order harmonic machinery shaft vibrations.
- Full API 670 Compliance: Fully satisfies stringent American Petroleum Institute requirements for machinery protection system sensor durability, linearity, and interchangeability.
- Global Hazardous Area Approvals: Certified under ATEX, IECEx, and CSA. It can be used in Zone 0, Zone 1, and Class I Division 1 hazardous environments as part of a properly approved system.
- High Temperature Operational Range: Designed to work in harsh turbine conditions, typically from -35°C up to around +177°C. It’s commonly installed inside gas turbines and steam turbine enclosures where temperature and vibration are both high.
- 3300 XL System Integration: It works with the 3300 XL system, usually paired with 330130 extension cables and 330180 Proximitor sensors. This combination is used to form standard 5 m or 9 m machinery protection loops in industrial applications.
Applications
- Shaft Radial Vibration Measurement: Captures dynamic motion profiles within fluid-film bearings to detect unbalance, misalignment, and shaft rubbing.
- Axial Thrust Position Sensing: Monitors rotor axial displacement relative to the thrust bearing to prevent catastrophic internal contact within casings.
- Shaft Eccentricity Monitor: Measures slow-roll thermal rotor bow during machine startup and shutdown phases prior to machine acceleration.
- Rotational Speed & Keyphasor Detection: Provides precise phase angle and speed reference data via non-contact sensing of shaft keyways or gears.
- Steam Turbine Instrumentation: Deployed in demanding turbine enclosures to track rotor vibration, casing expansion, and differential expansion.
- Gas Turbine Asset Protection: Operates in high-temperature turbine environments to provide continuous condition monitoring of main shaft bearings.
- Centrifugal Compressor Monitoring: Safeguards high-speed multi-stage compressors in critical processes against structural oil film instabilities.
- Industrial Pump & Fan Protection: Commonly used on large cooling water pumps, induced draft fans, and ventilation systems in heavy industrial plants. It gives continuous monitoring for rotating equipment that runs 24/7.
- API 670 Compliant Safeguarding: Used as the front-end sensing element in Machinery Protection Systems (MPS). When installed as part of a full 3300 XL loop, it supports API 670 protection requirements for critical rotating machinery.
- Emergency Shutdown System (ESD) Input: Provides real-time vibration signals that can be fed into trip or protection logic. In practice, it helps the control system trigger automatic shutdown when abnormal vibration levels are detected.
- Hazardous Area Field Installation: Suitable for installation in hazardous oil, gas, and chemical environments when used with proper system certification. It follows ATEX, IECEx, and CSA requirements for explosive atmosphere applications.
- Bently Nevada 3500 Loop Integration: Integrates into Bently Nevada 3500/40M or 3500/42M monitor cards through standard Proximitor sensor networks.
Service Advantages
- Rapid Response Time: We usually get quotations out within 24 hours. It’s not just fast reply, more like trying to keep the purchasing process moving without unnecessary waiting.
- Massive Ready Stock: A lot of industrial automation parts are kept in stock, including common and some hard-to-find items. In most cases, shipment can be arranged right away once order is confirmed.
- Express Global Shipping: We work with major international couriers, so delivery is generally around 3 to 5 business days worldwide, depending on destination and customs.
- Professional Technical Support: There is an engineering team that helps check cross-references, model compatibility, and configuration details when needed. This is especially useful for replacement or system matching cases.
- Customer-Centric Service: Each account is usually handled by a dedicated contact person. Communication can be done in multiple languages, and the support style is more practical and responsive rather than formal or rigid.
Frequently Asked Questions
Q1: What exactly does 330104-00-11-10-02-05 mean?
A1: It’s a version of Bently Nevada 3300 XL 8mm proximity probe. 330104 is the base model, the rest is configuration. M10×1 threaded housing, no unthreaded section, body length around 110 mm. 1.0 m integral cable with stainless steel armor. ClickLoc connector. Usually with ATEX, IECEx, CSA approvals depending on supply.
Q2: Is the 330104-00-11-10-02-05 compliant with API 670?
A2: Yes, but only in a full system. Probe alone is not enough. It needs 3300 XL Proximitor and extension cable together. Once connected, it meets API 670 like 7.87 V/mm (200 mV/mil). Common in turbine and compressor protection.
Q3: Can the 330104-00-11-10-02-05 be used in hazardous areas?
A3: Yes. “05” means multiple approvals including ATEX, IECEx, CSA. Can be used in Zone 0, Zone 1, Class I Division 1, depending on system certification.
Q4: What does the 330104-00-11-10-02-05 measure?
A4: Non-contact measurement of rotating shafts. Vibration, axial position, shaft movement, speed / Keyphasor signals. Used in steam turbine, gas turbine, centrifugal compressor.
Q5: How is the 330104-00-11-10-02-05's durability?
A5: PPS tip, 304 stainless steel body. Works in oil mist, vibration, higher temperature up to around 177°C. Armored cable helps protect during installation and operation.
Q6: What is needed for a full system loop with the 330104-00-11-10-02-05?
A6: Probe has only 1.0 m integral cable, not a full system. Needs 3300 XL Proximitor and extension cable. Usually 330130 cable with 330180 Proximitor to complete the loop for MPS.
