Bently Nevada 330930-065-01-05 6.5 Metres Proximity Transducer Extension Cable with Stainless Steel Armor and FEP Jacket
| Parameter / Item | Technical Data (330930-065-01-05) |
|---|---|
| Manufacturer / Series | Bently Nevada / 3300 NSv System |
| Full Part Number | 330930-065-01-05 |
| Total Cable Length (065) | 6.5 Metres (Approx. 21.3 feet) |
| Mechanical Protection (01) | Stainless Steel Armor |
| Outer Cable Jacket (01) | FEP (Fluorinated Ethylene Propylene) |
| Agency Approvals (05) | Multiple Hazardous Area Approvals |
| Operating Temperature | -51°C to +177°C (-60°F to +351°F) |
| Minimum Bend Radius | 25.4 mm (1.0 inch) |
| Connector Type | Miniature coaxial (ClickLoc design) |
| System Compatibility | 3300 NSv Proximity Probe & Proximitor |
- Fast Delivery: We usually keep a solid stock of critical parts, so you don’t really have to wait for long factory lead times when something urgent comes up in maintenance.
- Technical Precision: Everything supplied is 100% genuine original hardware, matched to the required system specifications — nothing mixed, nothing questionable.
- Cost Efficiency: And because of our global sourcing setup, pricing tends to stay competitive, plus shipping is handled in a way that helps reduce unexpected downtime as much as possible.
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
This version uses a 75Ω coaxial cable design for stable eddy current signal transmission. The “01” option means FEP jacket insulation with a stainless steel armor cable, so it is generally a better fit for rough industrial conditions. A ClickLoc coaxial connector is also included to keep signal connection stable when vibration levels are high.
As for the “05” code, that mainly relates to international approvals for hazardous area instrumentation.
Together, they make the standard 7-meter system length required by the 3300 XL NSv Proximitor Sensor. If probe length changes, calibration can drift. For axial position monitoring or radial vibration measurement, the signal may start looking off even when the sensor itself seems fine.
Thanks to the FEP jacket insulation and armored construction, operating temperature is roughly -51°C to +177°C. In a machinery protection system, installers usually insulate connectors when routing through conduit or junction boxes to avoid grounding issues.
| Part Number | Compatible With |
|---|---|
| 3500/42E | 330910-03-09-05-02-05 |
| 3500/50E | 330709-000-070-10-02-00 |
| 330101-30-63-10-02-00 | 3500/61 163179-02 |
| 330130-035-00-CN | 1900/65A 172323-01/1900/65A 167699-02 |
| 330130-035-01-CN | 3500/15 106M1079-01 |
| 330130-045-01-CN | 3500/65 145988-02 |
| 330104-00-07-05-02-00 | 3500/92 136180-01 |
| 330130-085-01-00 | 3500/94 145988-01 |
| 40113-02 | 330104-00-10-10-02-05 |
| 330130-035-00-00 | 330910-00-05-10-02-00 |
| 330130-040-00-CN | 3500/44M 176449-03 |
| 84661-50 | TK3-2E 14700-02A |
| 330130-045-03-05 | 3500/42M 140734-02 |
| 330703-000-060-10-02-00 | 3500/92 |
| 106M1081-01 | 330103-00-05-10-02-00 |
| 3500/42M 176449-02 | 330703-000-060-10-02-00 |
| 3500/15 AC 127610-01 | 330103-00-09-10-02-00 |
| 128276-01E 131151-01 | 135813-01 |
| 18745-04 | 990-05-XX-01-00 |
| 330102-22-58-10-02-00 | 330180-X1-05 MOD:145004-02 |
