330173-00-05-10-12-00 Bently Nevada 3300 5 mm Proximity Probe
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
330173-00-05-10-12-00 Bently Nevada 3300 5 mm Proximity Probe
Option Code Breakdown
- 330173: 3300 5 mm Proximity Probe, M8 x 1 thread, no armor
- 00: 0.0 mm unthreaded length
- 05: 50 mm total case length
- 10: 1.0 meter (3.3 feet) system length
- 12: Miniature coaxial ClickLoc connector with FluidLoc cable
- 00: No agency approvals
Key Technical Specifications
- Application: Measures radial/axial position and vibration
- Range & Scale: 0.25 to 2.3 mm linear range with a 7.87 V/mm (200 mV/mil) scale factor
- Temperature Range: -35°C to +177°C (-31°F to +351°F)
- Materials: PPS probe tip and stainless steel case
Amikon supplies industrial automation spare parts, mainly PLC, DCS, and TSI systems, to more than 160 countries.
- North America: Steady demand, especially US and Canada. Oil & gas plants and automotive-related production sites
- Europe: Similar in scale, Germany and UK stand out. Chemical plants and heavy equipment lines
- Middle East and Africa: Refinery projects and mining sites. UAE, Saudi Arabia, South Africa, and remote field installations
- Asia-Pacific: Broad demand from China, Singapore, Australia, India. Semiconductor fabs to power stations and metallurgy plants
- South America: Smaller volume but stable. Brazil, Chile, Argentina for mining, copper operations, and hydropower projects
Request a Quote Now
Contact: Miya Zheng
Email: sales@amikon.cn
WhatsApp: +86 180 2077 6792
100% Original Parts - Vetted industrial automation & DCS/PLC spares
Massive Inventory - 30,000+ items ready for immediate shipment
12-Month Warranty - Fully covered by a 1-year quality guarantee
Fast Global Shipping - Secure express delivery to 160+ countries
24/7 Rapid Response - Dedicated 1-on-1 customer service
Q1: What are the structural specifications and configuration details of the Bently Nevada 330173-00-05-10-12-00 proximity probe?
A1: It’s a 3300 series 5 mm proximity probe, 330173-00-05-10-12-00. M8 x 1 thread, 50 mm case, 1.0 m system length. ClickLoc connector with FluidLoc cable. No hazardous area rating, so it’s mostly used in standard rotating machinery setups rather than special zones.
Q2: What is the linear range and scale factor of the 330173-00-05-10-12-00?
A2: Around 2.0 mm (80 mils) linear range, with the usual 1.27 mm gap reference. On AISI 4140 steel, it stays at 7.87 V/mm (200 mV/mil). Pretty much the normal behavior you’d expect from a 5 mm 3300 probe in vibration monitoring or shaft position work.
Q3: Where is the 330173-00-05-10-12-00 normally used?
A3: You’ll see it in tight spots more than anything else—fluid-film bearings, thrust measurement points, sometimes retrofit work where space is limited. FluidLoc cable helps a bit with oil or moisture creeping along the cable, which is not always obvious until you run into it in the field.
Q4: Does the 330173-00-05-10-12-00 need an extension cable with a 3300 XL Proximitor sensor?
A4: No, it doesn’t. The probe is already a 1.0 m system length, so it goes directly into a 3300 XL Proximitor sensor. In practice, most setups just keep it simple and skip extra extension cabling.
Q5: What are the installation torque and temperature limits for the 330173-00-05-10-12-00?
A5: Torque is about 5.1 N·m (45 in-lb), nothing special there. Temperature range is -35°C to +177°C, which is enough for turbines, compressors, and most industrial rotating machinery environments.
