330103-00-03-50-02-00 Bently Nevada 3300 XL 8 mm Proximity Probe
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
330103-00-03-50-02-00 Bently Nevada 3300 XL 8 mm Proximity Probe
Non-contact eddy current proximity probe, mainly for shaft vibration, position and speed measurement on rotating machinery like turbines, compressors and pumps.
Configuration Details
- Model: 3300 XL 8 mm Probe (Metric M10 x 1 threads, no armor)
- Dimensions: 0 mm unthreaded length | 30 mm overall case length
- Cable: 5.0 meters (16.4 feet) standard cable
- Connector: Miniature coaxial ClickLoc connector
- Approvals: Standard version (no hazardous area certifications)
Core Specifications
- Linear Range: 2.0 mm (80 mils)
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Temperature: -52°C to +177°C
Global Distribution Network
Amikon supplies industrial automation spare parts, mainly PLC, DCS, and TSI systems, to more than 160 countries.
- North America: Steady demand, especially US and Canada. Oil & gas plants and automotive-related production sites.
- Europe: Similar in scale, Germany and UK stand out. Chemical plants and heavy equipment lines.
- Middle East and Africa: Refinery projects and mining sites. UAE, Saudi Arabia, South Africa, and remote field installations.
- Asia-Pacific: Broad demand from China, Singapore, Australia, India. Semiconductor fabs to power stations and metallurgy plants.
- South America: Smaller volume but stable. Brazil, Chile, Argentina for mining, copper operations, and hydropower projects.
Service Features
100% Original Parts - Vetted industrial automation & DCS/PLC spares
Massive Inventory - 30,000+ items ready for immediate shipment
12-Month Warranty - Fully covered by a 1-year quality guarantee
Fast Global Shipping - Secure express delivery to 160+ countries
24/7 Rapid Response - Dedicated 1-on-1 customer service
Frequently Asked Questions
Q1: What are the exact physical and mechanical dimensions of the Bently Nevada 330103-00-03-50-02-00 proximity probe?
A1: This Bently Nevada 330103-00-03-50-02-00 is an 8 mm probe from the 3300 XL 8mm Proximity Probe series. Body style is M10x1 fully threaded metric probe, case length is 30 mm, and there is no unthreaded section. It comes with a fixed 5 m integrated cable sensor, unarmored, so no extension cable is involved in this configuration.
Q2: Does the 330103-00-03-50-02-00 need an extension cable?
A2: No, it doesn’t use an extension cable. The 330103-00-03-50-02-00 already includes a 5 m integrated cable sensor, so it runs straight into a 3300 XL Transducer System with a 3300 XL Proximitor Sensor (330180 Proximitor). Basically it’s a direct 5-meter run from the probe to the proximitor, no intermediate cable section needed.
Q3: What connector is used and is the 330103-00-03-50-02-00 protected?
A3: It uses a ClickLoc coaxial connector probe type. The connector is standard gold-plated, but there’s no built-in protection boot on this version. In oily or humid turbine areas, users often add external protection to keep the connection stable.
Q4: What are the material and electrical specs of the 330103-00-03-50-02-00?
A4: It’s typically tuned for AISI 4140 steel targets and works with a 200 mV/mil (7.87 V/mm scale factor probe) setup. Linear range is around 2.0 mm. In normal eddy current transducer system use, it’s stable for vibration and displacement monitoring.
Q5: Is the 330103-00-03-50-02-00 probe suitable for hazardous areas?
A5: No. The -00 suffix means no hazardous-area certification, so it’s a standard industrial version only.
Q6: Where is the 330103-00-03-50-02-00 probe normally used?
A6: Mostly on compact rotating equipment—things like steam turbine vibration probe points, compressors, and bearing housings. It’s commonly selected for shaft vibration measurement, axial position, and general rotating machinery monitoring where installation space is tight.
