330104-06-14-10-02-00 Bently Nevada 3300 XL 8mm Proximity Probe
Price:
66USD
MOQ:
1
Delivery Time:
2-3 work days
Brand:
Bently Nevada
Product Description
330104-06-14-10-02-00 Bently Nevada 3300 XL 8mm Proximity Probe
- Base Probe (330104): 3300 XL 8 mm Probe with M10 x 1 metric thread and integral cable armor for maximum mechanical protection.
- Unthreaded Length (06): 60 mm smooth barrel section.
- Overall Case Length (14): 140 mm total threaded housing length.
- Total Cable Length (10): 1.0 meter (3.3 feet) integrated cable.
- Connector Type (02): Miniature coaxial ClickLoc connector with a standard cable sleeve.
- Agency Approval (00): No approvals required (Standard safe-area application).
Global Distribution Network
Amikon supplies industrial automation spare parts, mainly PLC, DCS, and TSI systems, to more than 160 countries.
- North America: Steady demand, especially US and Canada. Oil & gas plants and automotive-related production sites.
- Europe: Similar in scale, Germany and UK stand out. Chemical plants and heavy equipment lines.
- Middle East and Africa: Refinery projects and mining sites. UAE, Saudi Arabia, South Africa with remote field installations.
- Asia-Pacific: Broad coverage including China, Singapore, Australia, India. Semiconductor fabs, power stations, and metallurgy plants.
- South America: Stable volume from Brazil, Chile, Argentina. Mining, copper operations, and hydropower projects.
Request a Quote
- Quality & Service Commitment
- 100% Original Parts - Vetted industrial automation & DCS/PLC spares
- Massive Inventory - 30,000+ items ready for immediate shipment
- 12-Month Warranty - Fully covered by a 1-year quality guarantee
- Fast Global Shipping - Secure express delivery to 160+ countries
- 24/7 Rapid Response - Dedicated 1-on-1 customer service
Technical Specifications & Applications
Q1: What are the specifications of the 330104-06-14-10-02-00?
A: For this model, the complete ordering code is more useful than the probe name alone because every section represents a different option. 330104-06-14-10-02-00 is a Bently Nevada 330104 3300 XL 8mm Probe built with an M10 × 1 thread, a 60 mm unthreaded barrel, 140 mm overall length and a 1.0 m integral cable. Stainless steel cable armor and a miniature ClickLoc connector are included. The 00 ending indicates the standard version intended for safe-area service in a 3300 XL Proximity Transducer System.
Q2: Where is the 330104-06-14-10-02-00 usually found?
A: Ask different plants and you'll probably get similar answers. This probe is a familiar sight on steam turbines, gas turbines, centrifugal compressors and large pumps with fluid-film bearings. Some sites mainly use it for shaft displacement, others focus on non-contact vibration measurement, while certain systems also rely on it as a Keyphasor reference sensor. The application changes from site to site, but its role in machinery condition monitoring stays much the same.
Q3: Does buying the 330104-06-14-10-02-00 complete the system?
A: No. The probe is only one component. A compatible 3300 XL Proximitor Sensor and the correct 3300 XL Extension Cable still have to be added before the Eddy Current Transducer System is complete. Because this version already leaves the factory with a 1.0-meter cable attached, a 4-meter extension is commonly used for a 5-meter system, while a 9-meter arrangement normally uses an 8-meter extension instead.
Q4: Is the 330104-06-14-10-02-00 suitable for the Bently Nevada 3500 System?
A: It is, provided the matching transducer components are used. Once the signal has been processed by the 3300 XL Proximitor Sensor, it can be received by the Bently Nevada 3500 System for continuous shaft and vibration monitoring. That combination is seen quite often on equipment designed around API 670 Machinery Protection System practices.
Q5: Why is the 330104-06-14-10-02-00 cable protected with stainless steel armor?
A: The answer has more to do with the installation environment than the probe itself. Cables are sometimes routed through areas where vibration, heat, oil or accidental contact can't really be avoided. The armor helps reduce physical damage during long-term operation, which is one reason many users continue to choose the armored Bently Nevada Proximity Probe when replacing an existing unit.
