Dongfeng 4X2 LED Mobile Display Screen Truck Truck

Price Negotiable

Price: 15000-35000 per unit

MOQ: 1

Delivery Time: Negotiable

Brand: CLW

Product Description

Dongfeng 4x2 LED Mobile Display Screen Truck Advertisement Truck

Products Catalog:

LPG Tank Truck Trailer/ Fuel Tanker Truck/ LPG station
Water truck / Water Tank Truck / Water Sprinkler Truck/Water Tanker
Truck with crane / Truck mounted crane
Dump Truck / Tipper Truck/Side Tipper/End Tipper
Fire Fighting Truck / Fire Truck / Fire Vehicle
Concrete Mixer Truck
Van truck /Refrigerated truck
Fecal suction truck / Sewage suction truck
Cement Powder Tank truck/ Bulk cement truck
High-altitude operation truck
Self-loading garbage truck, garbage compactor truck, sealed garbage truc
Tractor
High Pressure Cleaning Truck
Sweeper Truck
Semi Trailer ( flat bed trailer / skeleton trailer / dump semi trailer / side wall trailer / low bed trailer / van container trailer / warehouse trailer, etc. )

Product Description:

1. Purpose: For mobile advertising, products promotion, branding, draft activities, concerts, and sport events, etc.

2. Main parts: LED screen, Generator set, Computer, Control system etc.

Specification:

Specification
Item No.		Parameters
Drive model		4x2, 6 Wheels
Overall Dimension		5995×2100×3000(mm)
Chassis Brand		Dongfeng
Cabin		Single, Left Hand Driving, with ABS
Engine	Model	Chaochai100HP, 4 Cylinders
	Power	74KW/100HP
	Emission standard	EURO 3
	Displacement	3500(ml)
	Fuel type	Diesel
Gearbox		5 Forward & 1 Reverse Gear
Brake System		Air/Oil Break
Steering Gear		Power Assistant
Wheel Base		3300(mm)
Front/Rear Axle Loading		1500/3000(Kg)
Approach/Departure Angle		24/16(°)
Tire		7.00R16
Max Driving Speed		100(km/h)
Upper Structure
LED Screen	Right LED Screen		3840mm(L)×1728mm(H)=6.63m2 P6 full-color Screen
	Left LED Screen		3840mm(L)×1728mm(H)=6.63m2 P6 full-color Screen
	Rear LED Screen		1280mm(L)×1440mm(H)=1.84m2 P6 full-color Screen
	P6 full-color outdoor LED display, waterproof, shake-proof, high brightness, long life
Multi-media system	1. 1 unit computer 2. Sound system including 4 units waterproof loudspeaker 1 unit power amplifiers
Generator Set	1. OUMA brand, Silent diesel generator 2. 220V domestic power supply
Security system	Overheat protection
Remarks	1. Circulating ventilation and cooling systems 2. Aluminum patterned floor 3. Internal and external electrical distribution box
Optional Items	1. Mobile stage 2. Scrolling light box
