Dongfeng Kr 25m 26 Meters Hydraulic Lifting Platform Truck, Man Lift
Price:
15000-35000 per unit
MOQ:
1
Delivery Time:
Negotiable
Brand:
CLW
Product Description
High Quality Dongfeng Kingrun 25m 26 Meters Hydraulic Lifting Platform Truck, Man Lift
Product Description
Automatic Bucket Balance System, Bucket will be Stayed in Balance Level in All Working Time.
- The Stretching Angle Up to 80°, which will be Easier to Handle in All Time.
- Full Computer Control System with Danger Waring System.
- LCD Screen in Both the Bucket and Truck to Display the Working Status.
- Rectangular Shape Arms to Increase the Arm Strength.
- V Shape Leg, H Shape Leg can Adapted to Different Road Condition Increasing the Stability.
Product Parameters
| GVW13280kg Driving Type 4x2 | |||
| Chassis brand | DONGFENG Tianjin | ||
| Cab | Tianjin a row and a half deluxe cab(with sleeping berth),hydraulic mechanical flip, channel type instrument panel, air conditioner, allowable 3 passengers | ||
| Engine(Hp) | 190 | ||
| Power(Kw) | 140 | ||
| Wheelbase | 4700 | ||
| Front/Rear Suspension | 1430/2230 | ||
| Steering | Power steering | ||
| Approach/departure angle | 20/13 | ||
| Wheels & tire | 10.00R20 | ||
| Tire number | 6+1 | ||
| Working height(m) | 28 | ||
| RHD or LHD | LHD | ||
| Overall Dimensions(mm) | 9600*2500*3850 | ||
| Curb weight (Kg) | 13085 | ||
|
Engine |
Model | B190-33 | |
| Horsepower | 190 | ||
| Maximum output Kw | 140 | ||
| Maximum torque N.m | 640 | ||
| Type | 6cylinders, in-line,4-stroke,water-cooled,turbo inter-cooling, diesel engine | ||
| Displacement | 5900ml | ||
| Euro 3 | |||
| Driving passenger | 2,3 | ||
| Transmission | 8 speed forward and one reverse, manual | ||
| Front Axle | 5T | ||
| Rear Axle | 10T | ||
| Brake System | air brake | ||
| exhaust brake | |||
| Color and LOGO | customized | ||
| Electric system | 24V | ||
|
Standard configuration |
Synchronous telescopic can be rotated 360 degrees continuously, H-shaped legs can be adjusted separately, electrical operation of working platform and ground remote control, hydraulic operation of turntable, load-sensitive proportional control system, stepless speed regulation, hydraulic automatic leveling, standard work bucket Weighing device, automatic interlocking device for loading and unloading, wind speed detection function, emergency electric emergency pump, emergency stop device, night safety warning device, vehicle horizontal state tester, remote engine ignition and flameout, real-time communication wireless intercom function, computer control , automatic limiting, dangerous work alarm, excellent safety performance. Both the upper and lower vehicles have displays to display the working conditions of the vehicle in time. | ||
|
Equipment |
Platform Dimension | 1100X570X1000mm | |
| Max Working Height | 28m | ||
| Max Working Radius | 12.6m | ||
| Angle Of Rotation | 360° | ||
| Platform Loading | 220kg | ||
| Platform Passenger | 2 | ||
| Working arm | 5 section | ||
| Delivery date | Within 30 days after receipt advance | ||
| Packing | Nude Pack .The packing of the commodity shall be in accordance with the export standard packing of the manufacturer, be suitable for long distance transportation of ocean and inland. The Seller shall be take measures against moisture, shocks and rust according to the special needs of the commodity. | ||
