FOTON 6X4 Concrete Cement Mixer Truck 375HP With Fully Hydraulic System
FOTON 6X4 Concrete Cement Mixer Truck
- Economical & Efficient & Valuable
- Famous DONGFENG chassis
- High quality DONGFENG engine
- Famous motor
- High efficiency gearbox
- Quality Oil pump
| Vehicle Parameters | |||
| Vehicle Model | CLW5250GJBA | Vehicle Brand | CLW |
| Overall dimensions | 8100X2500X3750mm | Curb weight | 12300kg |
| Loading capacity | 10m3 | Color | optional |
| Chassis Parameters | |||
| Chassis model | DFL5250GJBA | Chassis brand | DONGFENG |
| Overall dimensions | 8090x2500x3030mm | Wheel base | 3800+1350mm |
| Cab | D310 Sleeper cab, forward control type, low roof, new face, all welded steel cab of tilt type, mechanical cab tilting, rear mechanical cab suspension , adjustable driver’s seat, air conditioning system | ||
|
Engine |
Dongfeng L375 30 | ||
| Horse power | 375hp | ||
| Emission | Euro 3 | ||
| Displacement | 8900ml | ||
| Tire | 315/80R22.5 | Transmission | 9JS150T-B DD 9 forward & 1 reverse |
| Steering device | Power assisted steering | Steering wheel | Left hand drive |
| Concrete Mixer Structure Parameters | |||
| Mixing capacity(m³) | 10 | Color and Logo | Optional |
| Feeding speed (m³/min) | ≥5 | Discharge speed(m³/min) | ≥3 |
| Discharge residual rate | ≤0.5% | Slump scope(mm) | 50-210 |
| Water tank capacity(L) | 300 | Water pressure(Mpa) | 0.35-0.38 |
| Tank material | 5mm alloy steel | Tank front head | 8mm alloy steel |
| Standard Configuration | chassis, sub frame, mixer tank, reducer, hydraulic pump, hydraulic motor, radiator, water tank, cleaning hose, feed port, discharge port, climbing ladder, air pressure water supply device. | ||
We will test each product before shipment, and also provide online or face to face operation training for customer
We will discuss with R&D about the questions and feedback from customer to ensure all the quality of products and after-sales service.
- What is your terms of payment?
T/T with 30% deposit, and 70% balance will be paid before delivery.
We will show you photos of the products and packages before you paying the balance. - What's your MOQ?
1 set.
- How about delivery time?
25 workdays after we received 30% of contract value T/T down payment. customized types depends on configuration and order quantity.
- Do you have advantage on price?
We offer all the trucks with factory directly selling price.
- How about the afer-sales service?
Our engineer will be ready to offer online-supporting for any technical questions for you.
