Waste Recycling Organic Fertilizer Production Line Plant Machinery Pelletizer
Price:
Negotiable
MOQ:
1
Delivery Time:
30 work days
Product Description
5T/H High-Efficiency Powder Organic Fertilizer Line
Organic Waste Recycling to Large-Scale Harmless Fertilizer
Production Process Overview
The raw materials first enter the continuous aerobic fermentation system and undergo three stages: pre-heating (50-60℃), high-temperature decomposition (65-70℃), and cooling & maturation (≤45℃). This three-stage process ensures full decomposition of organic matter, harmless treatment (killing ≥99% of harmful bacteria and parasite eggs), and stable nutrient conversion.
The decomposed materials (with moisture content 35-40%) form agglomerates, which are then crushed by a high-efficiency hammer crusher into uniform coarse powder (particle size ≤10mm).
The crushed materials pass through a rotary vibrating screener (10-20 mesh adjustable) to remove impurities (stones, plastic, metal fragments) and oversized particles, ensuring the intermediate product meets the required fineness for subsequent processing.
The qualified powder is conveyed by a closed screw conveyor to an automatic quantitative packaging machine (weighing range 20-50kg/bag, error ≤±0.2kg), completing weighing, filling, heat-sealing, and finished product discharge. The final product is a uniform, odorless powder organic fertilizer meeting national agricultural standards.
Application Scope
This 5 T/H Powder Organic Fertilizer Production Line is specialized for large-scale organic waste treatment and high-yield fertilizer production, catering to diverse sectors including:
- Large-Scale Livestock and Poultry Breeding Farms: Resource utilization of cattle, sheep, pig, chicken, and duck manure (daily treatment capacity 40-100 tons)
- Professional Organic Fertilizer Manufacturers: Mass production of commercial organic fertilizer, improving soil fertility and supporting ecological agriculture
- Agricultural Waste Recycling Centers: Processing crop straw, corn stalks, bagasse, distiller's grains, and mushroom residues into high-value organic fertilizer
- Urban Environmental Protection Projects: Harmless treatment and resource recycling of urban sludge, kitchen waste, and food processing by-products
- Ecological Agriculture Bases: Self-production of organic fertilizer for green crop planting, realizing circular agricultural development
Product Highlights
- High-Capacity Stable Operation: Designed for 5 T/H continuous production (annual output 30,000-40,000 tons), with a fermentation system and crushing equipment matched to medium-scale production needs, ensuring 8-10 hours of uninterrupted operation
- Efficient Harmless Fermentation: Adopts intelligent temperature-controlled aerobic fermentation, shortening the maturation period to 7-10 days; high-temperature sterilization ensures product safety and compliance with national organic fertilizer standards
- Uniform High-Quality Finished Product: Equipped with a two-stage crushing-sieving process (primary coarse crushing + secondary fine crushing) and high-precision vibrating screener, resulting in powder fineness 10-60 mesh customizable, with uniform particle size and no impurities
- Semi-Automatic Energy-Saving Design: Integrates automatic conveying, screening, and packaging; key processes (fermentation temperature, feeding rate) are semi-automatic controlled, saving 30% labor compared to traditional lines; energy-efficient motors reduce operational costs
- Wide Raw Material Adaptability: Compatible with various organic wastes (livestock manure, straw, sludge, kitchen waste) with moisture content 55-70%, supporting flexible production and strong anti-interference to raw material quality
- Environmentally Friendly Configuration: Equipped with a deodorization system (optional) and closed conveying equipment, reducing odor emission and dust pollution; meets environmental protection emission standards
Technical Specifications
| Item | Specification |
|---|---|
| Model | Medium-Capacity Type (5T/H Standard) |
| Capacity | 5 T/H (Ton per Hour), continuous production |
| Layout Space | 400-500㎡ (including fermentation zone, processing zone, and storage zone) |
| Finished Powder Fineness | 10-60 mesh, customizable |
| Operation Mode | Semi-automatic (key parameters adjustable via control panel) |
| Motor Voltage | 380V/3Ph/50Hz (customizable for special voltage requirements) |
| Fermentation Cycle | 7-10 days (depending on raw material type) |
| Raw Material Moisture Requirement | 55-70% |
| Power Consumption | ≤80 kW/H |
| Labor Requirement | 3-5 operators per shift |
| Finished Product Moisture | ≤15% (meets national organic fertilizer standards) |
