BSC Standard All-In-One
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Product Description
Integrated All-in-One Design
Easy Installation & Quick Setup
CustomizedSolutions Available
Technical Specifications
| Product model | 138" | 168" | 220" | 135" | 162" | 216" |
| Product Type | SMD | GOB | ||||
| Size(inch) | 138 | 168 | 220 | 135 | 162 | 216 |
| Pixel Pitch(mm) | 1.5 | 1.9 | 1.2 | 1.5 | 0.9 | 1.2 |
| Overall Dimension(mm) | 3080x1840x28' | 3690x2183x28' | 4910x2869x28' | 3030.8x1812.9x31' | 3630.8x2150.4x31' | 4830.8x2825.4x31' |
| Net weight(kg) | 122 | 172 | 296 | 110 | 155 | 285 |
| Average power | 0.521 | 0.731 | 1.514 | 0.483 | 0.647 | 1.158 |
| consumption(kw) | ||||||
| Maximum power | 1.738 | 2.438 | 5.046 | 1.46 | 2.154 | 3.858 |
| consumption(kw) | ||||||
| Resolution | 1920x1080 | 1920x1080 | 3840x2160 | 1920x1080 | 3840x2160 | 3840x2160 |
| Contrast | 6500:01:00 | 15000:1 | ||||
| Grayscale | 14bit | 13~16bit | ||||
| Speaker unit | 4 full range units + 2 low frequency units | |||||
| Speaker maximum power | 120w | |||||
| Max. sound pressure level | 95dB | |||||
| Audio frequency domain | 60Hz~20kHz | |||||
| Refresh Rate | 3840Hz | |||||
| Brightness | 100~600cd/㎡(Adjustable) | |||||
| Viewing Angle(H/V) | 160°/140° | 165°/165° | ||||
| Input and output interface | Input:HDMI2.0 *1,HDMI1.4 *3,USB2.0 *1,USB3.0 *2,Type-C *1,POE *1,RJ45 *1,3.5mm Audio in *1,RS232 *1 | |||||
| Output:HDMI2.0 *1,3.5mm Audio out *2,USB *1 | ||||||
| Operating system | Android13.0,8G + 64G,Cortex-A76 ×4 + Cortex-A55 ×4 | |||||
| Optional Windows System | ||||||
| Cabinet material | Die-casting magnalium | |||||
| Installation method | Mobile Stand , Wall mounting, Ceiling-hanging | |||||
| Maintenance method | Front-maintenance | |||||
| Recommended viewing | ≥3.2 | ≥3.8 | ≥5.0 | ≥3.2 | ≥1.9 | ≥2.5 |
| distance(m) | ||||||
Aging test
References 1
References 2
References 3
References 4
