Automatic Corner Wrap Around Labeling Machine High Speed Carton Edge Label Applicator
Price:
Starting Price: USD 22,500
MOQ:
1
Delivery Time:
60 working days
Brand:
TOVOT
Product Description
High Speed Automatic Corner Labeling Machine With PLC Control And Automatic Product Detection
Automatic Corner Wrap Around Labeling Machine
High Speed Carton Edge Label Applicator
Automatic Corner Labeling Solution
The TOVOT Automatic Corner Wrap Around Labeling Machine is designed for precise corner and edge labeling of cartons, boxes, and other packaged products. The machine applies one label across two adjacent surfaces, creating clear product identification while improving packaging appearance and labeling consistency.
With automatic product detection, intelligent motion control, and high-precision label application technology, the system delivers reliable performance during continuous production. It can be integrated into existing conveyor lines or installed as an independent labeling station.
The modular structure allows flexible adjustment for different package sizes and labeling positions, making it suitable for a wide range of production requirements.
Benefits of Automatic Corner Wrap Around Labeling
Corner labeling helps improve product identification by allowing one label to remain visible from multiple viewing angles.
Compared with manual labeling, the automatic corner labeling machine improves production efficiency, maintains consistent label positioning, reduces repetitive work, and enhances packaging quality.
The system supports continuous operation and can quickly adapt to different package specifications through simple parameter adjustments.
Automatic vs Manual Corner Labeling
Production Efficiency
Manual corner labeling requires accurate positioning by operators, which can reduce production speed and affect consistency.
The automatic labeling machine synchronizes product movement and label application, maintaining stable performance throughout continuous production.
Label Position Accuracy
Manual application may cause label deviation or uneven alignment across the corner.
The automatic corner labeling system ensures smooth and accurate application on both surfaces with repeatable positioning.
Production Flexibility
Changing product dimensions manually often requires additional setup time.
The machine allows quick adjustment for different product sizes, label dimensions, and conveyor speeds, reducing production downtime.
Operation Process
Products enter the labeling station through the conveyor.
Sensors detect the product position and automatically activate the labeling cycle.
The labeling head dispenses the label and applies it across the product corner with synchronized movement, ensuring accurate placement and firm adhesion.
After labeling, products continue directly to the next production stage without interrupting production flow.
Optional modules such as automatic inspection, variable information printing, and production data communication can be added according to project requirements.
Key Features
- Automatic corner wrap around labeling
- High precision edge label positioning
- Stable continuous operation
- Automatic product detection
- Suitable for cartons, boxes, cases, and packaged products
- Flexible adjustment for different product sizes
- Support multiple label dimensions
- Easy conveyor integration
- Compact machine structure
- Customized solutions for different production layouts
Technical Specifications
| Item | Specification |
|---|---|
| Machine Type | Automatic Corner Wrap Around Labeling Machine |
| Product Type | Cartons Boxes Cases Packages |
| Labeling Speed | 30-80 Products/min |
| Labeling Accuracy | ±1 mm |
| Label Type | Self-Adhesive Labels |
| Labeling Position | Corner Edge Wrap Around |
| Control System | Industrial PLC Control |
| Power Supply | 220V / 380V |
| Rated Power | 2-3 KW |
| Air Pressure | 5-7 Bar |
| Conveyor Connection | Available |
| Design | Customized |
Optional Functions
Variable information printing, Barcode and QR code printing, Automatic label inspection, Vision positioning, Dual labeling heads, Automatic conveyor synchronization, Production data communication, Remote support
Applications
- Cartons
- Boxes
- Cases
- Flat Packages
- Building Material Products
- Paper Products
- Plastic Products
- Wood Products
- Warehouse Packaging
- Distribution Centers
- Automatic Packaging Lines
- Production Line Automation
Frequently Asked Questions
What is a corner wrap around labeling machine?
It is an automatic labeling system that applies one label across two adjacent surfaces, providing clear product identification and improving packaging consistency.
What products can be labeled?
The machine is suitable for cartons, boxes, cases, flat packages, and other products requiring corner labeling.
Can the machine work with different package sizes?
Yes. The labeling system can be adjusted and customized for different product dimensions and label sizes.
Can it be connected to an existing production line?
Yes. The machine supports integration with conveyor systems and automatic packaging equipment.
Is customization available?
Yes. We provide customized solutions based on product specifications, labeling positions, production capacity, and factory layout.
