Industrial PVC Hot Cold Mixer Unit 1300–1500Kg/Batch For SPC Flooring
Price:
Starting Price: USD 55,000
MOQ:
1
Delivery Time:
60 working days
Brand:
TOVOT
Product Description
Industrial PVC Hot Cold Mixer Unit With 315 KW Hot Mixer Motor Power 1300–1500 Kg/Batch Capacity And Alloy Steel Blade Material For SPC Flooring
Industrial PVC Hot Cold Mixer Unit for SPC Flooring Material Preparation
The PVC Hot Cold Mixer Unit is an industrial-scale material preparation system designed for mixing and cooling PVC compounds before extrusion processing. The complete system combines a high-speed heating mixer and a large-capacity cooling mixer to provide efficient blending, temperature control, and material stabilization.
Advanced Mixing Technology for Stable PVC Production
The quality of PVC products depends greatly on the uniformity of raw material mixing before extrusion. Different additives, fillers, and PVC resin need to be evenly dispersed to achieve consistent processing performance.
The PVC Hot Cold Mixer Unit uses a powerful high-speed mixing system to quickly blend materials and generate controlled friction heat. After the hot mixing process, the cooling mixer reduces the temperature evenly through water circulation.
This integrated mixing process improves material stability, shortens preparation time, and provides continuous raw material supply for modern extrusion production lines.
System Advantages
- High-capacity structure suitable for large-scale PVC and SPC flooring production
- High-performance motor system provides strong mixing force for different material formulations
- Wear-resistant alloy steel blades ensure long service life under continuous operation
- Cooling chamber design improves heat exchange efficiency and reduces material temperature quickly
- Complete unit can work with automatic loading, conveying, and storage systems
Working Principle
The PVC Hot Cold Mixer Unit operates through two connected mixing stages. First, raw materials are loaded into the vertical hot mixer. The high-speed blades create strong circulation and friction, allowing PVC resin and additives to achieve uniform dispersion while increasing temperature.
When the preset hot mixing condition is reached, the material is transferred automatically to the horizontal cooling mixer. The cooling mixer uses low-speed paddle rotation combined with water jacket cooling to remove heat evenly and maintain material consistency. After cooling is completed, the finished material is discharged automatically for extrusion production.
Application Areas
The PVC Hot Cold Mixer Unit is widely used in plastic material processing industries:
- SPC flooring production - prepares stable PVC compounds before extrusion and lamination processes
- PVC pipe and profile manufacturing - provides uniform mixing of resin, fillers, stabilizers, and processing additives
- WPC products, decorative boards, cable materials, and other plastic compound applications requiring large-volume mixing
Technical Specifications
| Item | Specification |
|---|---|
| Type | Hot & Cold Mixing System |
| Model | 1500/5000, 2000/6000 |
| Application | PVC, SPC Flooring, Plastic Raw Materials |
| Capacity | 1300-1500 kg/batch |
| Hot Mixer Motor Power | 315 kW |
| Cooling Mixer Motor Power | 75 kW |
| Blade Material | Alloy Steel |
| Hot Mixing Speed | 740 rpm |
| Cooling Mixing Speed | 50 rpm |
| Cooling Method | Water Circulation |
| Discharge Type | Automatic Pneumatic |
| Main Structure | Heavy Duty Steel Frame |
| Voltage | 380V Custom |
| Operation Mode | Automatic |
| Customization | Available |
Automatic PVC Material Preparation System
The PVC Hot Cold Mixer Unit can be integrated with automatic feeding systems, weighing equipment, vacuum conveying systems, storage tanks, and extrusion lines. Through automatic mixing, cooling, and material transfer, the system reduces manual operation requirements and provides stable material preparation for continuous industrial production.
Frequently Asked Questions
What is the main function of the PVC Hot Cold Mixer Unit?
The system is used for heating, mixing, and cooling PVC compounds to prepare uniform raw materials before extrusion.
What is the difference between 1500/5000 and 2000/6000 models?
The model number represents the hot mixer and cooling mixer capacity. The 2000/6000 model provides a larger processing volume for higher production requirements.
Is this mixer suitable for SPC flooring production?
Yes. It is commonly used in SPC flooring production lines for preparing PVC powder compounds before extrusion.
What control system is used for the machine?
The system can be equipped with PLC control for automatic operation, monitoring, and process adjustment.
Can the mixing system be customized?
Yes. Capacity, motor configuration, cooling structure, automation level, and layout can be customized according to production requirements.
