4 Channel Peristaltic Dosing Pump for Chemical Dispensing and Liquid Transfer
The 4 Channel Peristaltic Dosing Pump is designed for controlled chemical dosing, quantitative dispensing and liquid transfer in industrial and laboratory applications.
With a flow range of 0.007–6000 mL/min and support for up to 4 channels, the pump provides both flow mode and dispensing mode. A 5-inch industrial color touchscreen enables convenient operation, while RS485 communication with Modbus protocol supports integration with compatible automated control systems.
- Up to 4 Channels – Supports multi-channel liquid transfer and dosing configurations.
- Quantitative Dispensing – Programmable dispensing volume, time and cycle settings.
- Flow & Dispensing Modes – Suitable for continuous transfer and quantitative dispensing.
- 5-Inch Touchscreen – Industrial full-color display with intuitive touch operation.
- Flow Calibration – Calibration function helps maintain dosing accuracy.
- Automation Integration – RS485 / Modbus and optional external control interfaces are available.
| Parameter | Specification |
|---|---|
| Flow Range | 0.007–6000 mL/min |
| Speed Range | 0.1–600 rpm |
| Speed Resolution | 0.1 rpm |
| Maximum Channels | 4 |
| Operating Modes | Flow Mode / Dispensing Mode |
| Dispensing Volume | 0.01 μL–999.99 L |
| Dispensing Time | 0.1 s–999.9 h |
| Dispensing Cycles | 0–9999 (0 = Infinite Cycle) |
| Interval Time | 0–999.9 h |
| Display | 5-inch Industrial Full-Color LCD Touchscreen |
| Communication | RS485 / Modbus |
| External Input | 0–5 V, 0–10 V, 4–20 mA, 0–10 kHz (Optional) |
| Power Supply | AC 100–240 V, 50/60 Hz |
| Power Consumption | <200 W |
| Protection Grade | IP65 |
| Compatible Pump Heads | YZ1515, YZ2515, KZ25, DMD25 |
Suitable for a variety of liquid dosing and transfer applications, including:
Chemical Dosing · Quantitative Dispensing · Industrial Liquid Transfer · Laboratory Applications · Process Control · Flotation Reagent Dosing
Pump head and tubing should be selected according to the required flow rate, liquid properties and chemical compatibility.
1. Can this peristaltic pump support multiple channels?
Yes. The drive supports up to 4 channels depending on the selected pump head configuration.
2. Can it be used for quantitative dispensing?
Yes. Dispensing volume, dispensing time, cycle number and interval time can be set according to process requirements.
3. Can it be integrated into an automated control system?
Yes. The pump supports RS485 communication with Modbus protocol and optional external control interfaces.
