Street pole assembling machine for wind tower production line , Heavy light pipe welding machine

Name: Street pole assembling machine for wind tower production line , Heavy light pipe welding machine
Brand: Friendship Machinery Co., Ltd

Price Negotiable

Price: Negotiable

MOQ: 1

Delivery Time: 30 working days

Brand: FSM

Product Description

1. Simple introduction

This machine is suitable for following process of high mast making:

● Three hydraulic cylinder will clamping two pieces parts of high mast and do spot welding process.

● Press the high mast to making the bottom area round shape, in order to assemble the bottom flange

● Press the high mast for straightening after welding

2. Main parameter

No.	Item	Unit	Specification
1	Model	/	HAS-1000
2	Maximum diameter of the pole	mm	1000
3	Top cylinder working force	kn	1000
4	Top cylinder maximum stroke	mm	650
5	Top cylinder maximum distance from rod to worktable	mm	1150
6	Side cylinder output force	kn	300*2
7	Side cylinder stroke	mm	400
8	Side cylinder movement distance from upper to bottom	mm	430
9	Maximum working pressure	Mpa	25
10	Height above ground of worktable	mm	305
11	Column inner distance	mm	1450
12	Total motor power	kw	18.5 + 5.5
13	Weight	kg	4000
14	Overall size	mm	130019002400
