Automatic CNC Drilling Punching Marking Machine For Metal Sheet PPD103
Price:
Negotiable
MOQ:
Negotiable
Delivery Time:
Negotiable
Brand:
FRIENDSHIP MACHINERY
Product Description
Automatic CNC Drilling Punching Marking Machine For Metal Sheet PPD103
| No. | Item | Specification |
| 1 | Plate size | 1500*775 (for punching) |
| 1200*775 (for drilling) | ||
|
2 |
Maximum punching diameter * maximum plate thickness |
Ø25.5*25mm (material Q235 when the maximum tensile strength up to 500MPa) |
| Ø25.5*20mm (material Q345 when the maximum tensile strength up to 630MPa) | ||
| 3 | Plate thickness for punching | 5-25mm |
| 4 | Plate thickness for drilling | 20-40mm |
| 5 | Drilling diameter range | 12-50mm |
| 6 | Minimum margin between hole and plate side | 25mm |
| 7 | Maximum punching force | 950kN |
| 8 | Die numbers | 4 sets |
| 9 | Character size | 14*10*19mm |
| 10 | Character quantity for the character box | 10 nos |
