Unveiling the Power of RO3010 PCBs: The Ultimate Solution for High-Frequency Applications

In the world of advanced circuit materials, the RO3010 PCB stands out as a game-changer, offering superior performance and stability for high-frequency applications. At Bicheng, we are proud to introduce the RO3010 PCB, a 2-layer circuit board designed to meet the demands of modern technology and innovation.

Introduction of RO3010:
Rogers RO3010 advanced circuit materials are ceramic-filled PTFE composites known for their high dielectric constant and exceptional stability. These competitively priced products simplify the design of broadband components and find applications across a wide frequency range, making them ideal for circuit miniaturization.

Key Features:

• Dielectric constant of 10.2+/- .30 at 10 GHz/23°C
• Dissipation factor of 0.0022 at 10 GHz/23°C
• Low Coefficient of Thermal Expansion
• Thermal Conductivity of 0.95 W/mK
• Moisture Absorption of 0.05%
• Operating temperature range of -40℃ to +85℃

Benefits:

• Dimensional stability with expansion coefficient matched to copper
• Economical laminate pricing for volume manufacturing
• Suitable for multi-layer board designs

PCB Stackup:

• 2-layer rigid PCB
• Copper Layer Thickness: 35 μm
• RO3010 Substrate Thickness: 50mil (1.27mm)
• Finished Board Thickness: 1.4mm
• Surface Finish: Immersion Gold

Applications:

• Automotive radar applications
• Global positioning satellite antennas
• Cellular telecommunications systems
• Patch antennas for wireless communications
• Direct broadcast satellites
• Remote meter readers
• Power backplanes

Contact Info:
For any product questions or inquiries, please reach out to Sally at sales30@bichengpcb.com

Conclusion:
The RO3010 PCB from [Your Company Name] is the ultimate solution for high-frequency applications, offering unmatched performance, stability, and reliability. With its advanced features and benefits, the RO3010 PCB is paving the way for innovation in various industries. Contact us today to learn more about how the RO3010 PCB can elevate your next project to new heights.
