factory sale best price LPG storage tanks, ASME lpg tanker, bulk surface lpg gas storage tanker for propane for sale
factory sale best price LPG storage tanks, ASME lpg tanker, bulk surface lpg gas storage tanker for propane for sale
LPG storage tank is the stationary vessel to store LPG and widely used in various industries. We can provide different capacity and standard storage tank. It is designed according to new regulation with high safety performance and long durable time
These LPG storage tanks are equipped with all standard instruments and controls like Rochestr gauge, excess flow check valves, safety valves, Pr. gauges, LPG Transfer compressor, Valves, Piping, Drains, Pr.Regulators, Water sprinkling system , gas leak detection system & a suitable Control panel. Optionally a Digital weighing scale can also be supplied as an integral part.
Most LPG storage tanks in standby-plant service are steel, non-refrigerated pressure vessels. Tanks are available in many sizes for both aboveground and underground service. New propane tanks are built to ASME standards and are designed for at least 250 psig working pressure. Common tank sizes and approximate dimensions are shown in the chart below. Larger industrial and commercial applications generally use 18,000 gallon and larger tanks.
The LPG storage tank is inspected step by step, inspect the welding seam quality via nondestructive testing, pressure performance analysis of the case is also accomplished using the hydrostatic test.
If you're interested in our lpg gas pressure vessels, please send email to truck0011@163.com or talk to Anita directly by whatsapp/wechat/Mob.: +86 13329899995.
Technique Parameters of hot sale lpg gas storage tank as below
| Volume (cbm) | DN (mm) | Thickness (mm) | Quality(kg) | Overall Dimension(mm) | |||
| Shell | Head | Tank | Filling | ||||
|
Filling Medium propane Designed Pressure 1.77MPa Corrosion Allowance 1mm Medium Density 420kg/m3 Land propane LPG gas tank |
5(5.6) | 1600 | 10 | 10 | 2030 | 1995 | 3070*1620*2210 |
| 8 | 1600 | 10 | 10 | 2540 | 3192 | 4270*1620*2210 | |
| 10 | 1600 | 10 | 10 | 2950 | 3990 | 5260*1620*2210 | |
| 12 | 1800 | 10 | 12 | 3360 | 4788 | 5034*1820*2410 | |
| 15 | 1800 | 10 | 12 | 3920 | 5985 | 6224*1820*2410 | |
| 20 | 1800 | 10 | 12 | 4820 | 7980 | 8174*1820*2410 | |
| 20 | 2000 | 12 | 12 | 5150 | 7980 | 6724*2024*2614 | |
| 20 | 2100 | 12 | 12 | 5050 | 7980 | 6154*2124*2714 | |
| 20 | 2200 | 12 | 14 | 5080 | 7980 | 5608*2224*2814 | |
| 25 | 2000 | 12 | 12 | 6120 | 9975 | 8304*2024*2614 | |
| 25 | 2100 | 12 | 12 | 5970 | 9975 | 7594*2124*2714 | |
| 25 | 2200 | 12 | 14 | 6020 | 9975 | 7008*2224*2814 | |
| 32 | 2300 | 12 | 14 | 7110 | 12768 | 8158*2324*2914 | |
| 32 | 2400 | 14 | 14 | 7710 | 12768 | 7508*2428*3018 | |
| 50 | 2300 | 12 | 14 | 10190 | 19950 | 12508*2324*2914 | |
| 50 | 2400 | 14 | 14 | 11140 | 19950 | 11508*2428*3018 | |
| 50 | 2600 | 14 | 16 | 10910 | 19950 | 9912*2628*3218 | |
| 50 | 2700 | 14 | 16 | 10640 | 19950 | 9182*2728*3318 | |
| 50 | 2800 | 16 | 16 | 11470 | 19950 | 8612*2832*3422 | |
| 60 | 2700 | 14 | 16 | 12750 | 23940 | 10962*2728*3318 | |
| 65 | 2700 | 14 | 16 | 13590 | 25935 | 11832*2728*3318 | |
| 80 | 3100 | 16 | 18 | 17000 | 31920 | 11166*3132*3722 | |
| 80 | 3200 | 18 | 18 | 18140 | 31920 | 10516*3236*3826 | |
| 100 | 3100 | 16 | 18 | 20410 | 39900 | 13866*3132*3722 | |
| 100 | 3200 | 18 | 18 | 21800 | 39900 | 13016*3236*3826 | |
| 120 | 3400 | 18 | 20 | 24960 | 47880 | 13820*3436*4026 | |
| Material of tank and main pressure parts | Q345R/Q370R | ||||||
| Standard | GB150 TSG R0004-2009 | ||||||
| Safety valve of selection fitting | Safety valve, column magnetic reversible level meter, pressure gauge, thermometer, cut-off valve | ||||||
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
