factory sale 120,000L 50ton lpg gas storage propane tanker, hot sale bullet type bulk surface lpg gas storage tanker
factory sale 120,000L 50ton lpg gas storage propane tank, hot sale bullet type bulk surface lpg gas storage tank
factory selling customized 50 ton 120 cbm propane gas tank, lpg propane storage tank, lpg tank manufacturer
Factory selling high performance 5cbm lpg tank; 8cbm lpg tank; 10cbm lpg tank;12cbm lpg tank; 15cbm lpg tank; 20cbm lpg tank; 25cbm lpg tank; 32cbm lpg tank; 50cbm lpg tank; 60cbm lpg tank; 65cbm lpg tank; 80cbm lpg tank; 100cbm lpg tank; 120cbm lpg tank
Cheng Li LPG Pressure Vessel functional characteristics:
1. Anti-corrosion coating the surface .Using sand-blasting treatment, spraying, blowing, and other advanced technology.
2.High-quality home-made or imported Safety Accessories for users matching, fully furnished.
3.Strictly to science and the advanced construction technology to ensure that at low temperatures, the contraction rate of the highest dimensional stability.
4. rigorous quality testing: A, B Class 100% seam-ray testing, II level qualified C, D Class weld 100% magnetic particle inspection, I level qualified.
Tank shaped use the advanced welding technology, end socket arc butt welding, and the once-forming of composite steel-plastic technology. Equipped with active and passive safety devices to meet an emergency and can load and unload the material in long distance and completely close condition. Be applied to transport natural gas, liquefied petroleum gas, liquefied ammonia, carbon bisulfide, epoxy ethane, gas, butane, dimethylmethane, propylene, etc. Cross section of tank could be oval, round and round-square. heat insulation and heating device is optional.
Natural gas in normal temperature with low or medium pressure.
Tank volume various from 5 Cubic-200 cubic meters.
Our company has solid technology, flawless inspection, advanced equipments, reliant quality and flexible modes of operation. What’s more, it has roundly passed the ASME standard;ISO9001,the 3C(China Compulsory Certification) and BV factory audit.
If you're interested in our lpg gas storage tanker, please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of CLW brand surface lpg gas storage tanker manufactured by Chengli Special Automobile Co., Ltd. as below.
Main parameter of CLW ASME LPG storage tank
|
Technical Specification
|
Parameter | |
| Tank | Tank name | LPG storage tank |
| Model | CLW3400-120 | |
| Overall dimensions | 13820*3436*4026 mm | |
| Inner diameter | 3400mm | |
| Vessel type | on the ground | |
| Designing pressure | 1.77 Mpa | |
| Working pressure | 1.61 Mpa | |
| Designing temperature | -19~50 | |
| Filling medium | Liquid petroleum/propane gas | |
| Corrosion margin | 1.00 mm | |
| tank weight | 25000kg | |
| Full capacity | 50000kg 50ton 120 cbm | |
| Heat treatment | Bulk | |
| Filling factor | 420 Kg/ m³ | |
| Tanker & pressure parts material | Q345R | |
| Hydraulic test pressure | 2.22 Mpa | |
| Gas tight test pressure | 1.77 Mpa | |
| Produce standard | ASME standard and GB150 standard | |
| Optional accessories | afety valve,SCL-UHZ(magnetic flap gauge),pressure gauge,thermometer,cut-off valve etc. | |
| Liquid indicator | Model | UHZ-518C14 |
| Version | Magnetic | |
| Nominal pressure | 2.5 Mpa | |
| Scope of testing | 50~2500 mm | |
| precision | 2.5 | |
| Safety Valve | Model | A42F-2.5-80 |
| Version | Built-in | |
| Nominal pressure | 2.5 Mpa | |
| Nominal radius | DN80 | |
| Opening pressure | 1.68-1.76 Mpa | |
| Re-seating pressure | ≥0.8 Mpa opening pressure | |
| Handling System | Feed pipe | DN80 |
| Drain pipe | DN80 | |
| Admission port | DN50 | |
| Sewage outfall port | DN80 | |
| Vent nozzle port | DN80 | |
