new best seller forland 4*2 6.3tons truck with crane for sale, hot sale! factory sale forland truck mounted crane
new best seller forland 4*2 6.3tons truck with crane for sale, hot sale! factory sale forland truck mounted crane
Chengli Special Autmobile is the leading manufacturer and supplier of truck with crane in China. With many years’ development, Chengli Special Automobile Co., Ltd. could supply cargo truck with crane, dump truck mounted crane, crane truck, etc. More information, please feel free to contact with Ms. Anita.
The dump truck with crane is also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The dump truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional dump truck with crane manufacturer in China, the dump truck with crane for sale is from 2 ton to 32 ton. The drive type of our dump truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in truck with crane, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
|
Main Technical Parameter of Forland 4x2 Truck with Crane ,with 6.3Ton XCMG Crane |
||||
|
Product Model |
BJ5122V5PDB-A1 6.3TonTruck with Crane |
Overall Dimension(L*W*H)(mm) |
7990×2490×3000,3500 |
|
|
Wheelbase(mm) |
4500 |
Body internal Dimension(L*W*H)(mm) |
4800×2300×520 |
|
|
F/ R suspension(mm) |
1210/2280 |
Front/Rear tread(mm) |
1810 /1800 |
|
|
Gross weight (kg) |
12455 |
Number of Axles |
2 |
|
|
Payload(kg) |
4500 |
Total Mass of Quasi-trailer(Kg) |
/ |
|
|
Curb weight(kg) |
7760 |
F/R axle load(Kg) |
5600/6855 |
|
|
Approach/ departure angle (° ) |
28/23 |
Max Speed (km/h) |
80 |
|
|
Cab capacity |
3 |
Cab Type |
With the optional chassis |
|
|
Chassis Model |
BJ1122V5PDB-A1 |
Chassis manufacturer |
Beijing Foton Automobile |
|
|
Gear Box |
Foton 5 shift(145HF) |
Transmission type |
Manual |
|
|
Steering Type |
Power steering |
Traction Type |
4*2 |
|
|
Frame type |
Side rails |
Rear axle |
Foton 9ton(1108C) |
|
|
Brake System |
Air brake |
|||
|
Leaf Spring number |
10/11+9 |
Tire size/type |
9.00-20 14PR,9.00R20 14PR |
|
|
Engine Model |
YC4E135-33 |
Engine manufacturer |
Guangxi Yuchai |
|
|
Fuel type |
diesel |
Displacement(ml) |
4260 |
|
|
Emission stand |
Euro 3 |
Power(kw) |
100(136hp) |
|
|
Operation System |
Electrically Hydraulic Control |
Electric system |
24V |
|
|
Equipment & Performance |
Equipped with top quality XCMG straight arm SQ6.3SK3Q 4arms Crane, optional other series |
|||
|
Max lift quality: 6300kg, Crane Weight:2270Kg ,Max Lifting Moment:15.7(T.M) |
||||
|
Work radius: 11m, lift height:12.5m, span:5.6m |
||||
|
Operate left or right, up or down, and 360° rotation ,reliable quality, long service life, work fast |
||||
|
Optional 5ton,8ton,10ton,12ton,16ton,20ton crane, or optional 2 arms ,3arms, 4 arms or multi-arms, optional straight arm or folding arm |
||||
|
Design different form truck of crane as per the customer’ request ,as water truck with crane, etc.
|
||||
More pictures of hot sale forland truck mounted crane as below.
