Heavy duty SINO TRUK 8*4 HOWO 16tons Truck with Crane,factory sale best price Truck with XCMG Crane Truck with crane
Heavy duty 8*4 HOWO Truck with Crane, Truck with XCMG Crane Truck with 10ton crane, truck with 12ton crane
The dump truck with crane is also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The dump truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional dump truck with crane manufacturer in China, the dump truck with crane for sale is from 2 ton to 32 ton. The drive type of our dump truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Technical parameter of SINO TRUK HOWO 8*4 16tons-20tons truck with crane as below
| Products Technical Specification | ||
| Product Name | Sinotruk HOWO 8*4 Truck with crane | |
| Chassis Model | ZZ13317N | |
| Fuel type | Diesel | |
| Emission Standard | Euro 3 | |
| Cabin | HW76,with A/C,sleeper | |
| Whole Vehicle main dimensions (mm) |
Overall dimensions (L×W×H) | 11990*2500*3990 |
| Cargo bady dimensions | 8000*2390*800 | |
| Wheel base | 1800+4600+1350 | |
| Front overhang | 1500 | |
| Rear overhang | 2450 | |
| Min. ground clearance | 550 | |
| Weight data (kg) | G.V.W | 31000 |
| Curb weight (chassis) | 15500 | |
| Max payload | 25000-35000 | |
| Whole vehicle main performance |
Max. speed (km/h) | 95 |
| Max. slope of climb (%) | 30 | |
| Engine | Model | WD615.95E |
| Maximum power | 247kw / 336hp | |
| Number of cylinders | 6 | |
| Displacement (L) | 9.726 | |
| Engine Manufacturer | China National Heavy Duty Truck Group Co., Ltd. | |
| Gear box | Model | HW15710 |
| Number of gears | 10 forward gears & 2 reverse | |
| Axle | Front Load capacity (ton) | HF9 |
| Rear Load capacity (ton) | HC16 | |
| Suspension | Leaf spring, | 4/4/-,4/4/12,11/11/12,11/11/- |
| Steering Wheel | left/right hand drive | LHD |
| Brake system | Service brake | Air braking |
| Electric device | Rated voltage | 24V |
| Tyres & Quantity | 12.00R20 & 12+1 | |
| Crane Description | ||
| Brand | XCMG | |
| Type | Straight Crane | |
| Model | SQ14SK4Q | |
| Max Lifting Capacity (kg) | 14000 | |
| Maximum lift height (m) | 15.8 | |
| Max Lifting Moment (t.m) | 35 | |
| Max Oil Flow of Hydraulic System (L/min) | 63 | |
| Max Pressure of Hydraulic System (MPa) | 26 | |
| Oil Tank Capacity (L) | 160 | |
| Rotation Angle (°) | All Rotation | |
| Crane Weight (kg) | 4800 | |
| Installation Space (mm) | 1300 | |
| Working radius (m) | 2.5 / 5.0 / 8 / 11 / 13.2 / 15.8 | |
| Lifting capacity (kg) | 14000 / 6000 / 3500 / 2300 / 1800 / 1200 | |
More pictures of hot sale howo 8*4 truck with crane as below.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
