hot sale Forland 4*2 LHD 2tons telescopic boom mounted on truck, best price FORLAND 2,000kgs cargo truck with crane
hot sale Forland 4*2 LHD 2tons telescopic boom mounted on truck, best price FORLAND 2,000kgs cargo truck with crane
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck with crane in China. With many years’development, Chengli Special Automobile Co., Ltd. could manufacture and export 4*2 truck with crane, 4*4 cargo truck with crane, 6*4 dump truck with crane, 8*4 truck mounted crane, etc. And our CLW brand truck mounted crane are from 1tons to 20tons and heavy duty.
100tons/150tons/200tons crane truck, etc. More information, please feel free to contact with Ms. Anita. If you're interested in our truck mounted crane, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
main technical parameters of forland cargo truck with crane as below
forland mini 2tons truck with crane for sale
More information, please feel free to contact with us.
Email: specialtruck01atgmail.com; truck0011at163.com; truck8894atyahoo.com
|
Main Technical Parameter |
||||
|
ProductModel |
Crane Truck |
Gross Vehicle Weight (kg) |
4495 |
|
|
Curb Weight (kg) |
2680 |
Overall Dimension(mm) |
5995x2165x2850 |
|
|
Box inner dimension(mm) |
2600x1900x400 |
Cab Allowed Persons |
2+3 |
|
|
Axle No. |
2 |
Wheelbase (mm) |
3360 |
|
|
Chassis Technical Parameter |
||||
|
ChassisBrand |
Forland |
Chassis Name |
Truck Chassis |
|
|
Overall Dimension (mm) |
5535×2065×2280 |
Tyre No. |
6with 1 spare tyre |
|
|
App./ Dep. Angle(º) |
31/20 |
Tyre Spec. |
7.00-16 |
|
|
Leaf Spring No. |
8/9+8 |
Front Track (mm) |
1510 |
|
|
Fuel Type |
Diesel |
Rear Track (mm) |
1590 |
|
|
Drive Type |
4x2 |
Brake System |
Air brake |
|
|
SteeringType |
Power-assisted steering wheel |
Gear Box |
5speed forward and 1 reverse |
|
|
Engine Technical Parameter |
||||
|
Engine Model |
YN33CRD2 |
Emission Standard |
Euro III |
|
|
Displacement ( ml) |
3298 |
Power (HP/KW) |
102/75 |
|
|
Cylinder No. |
4in line |
Engine Type |
Water cooling, four stroke, inter-cooling charged, |
|
|
Crane Technical Parameters |
||||
|
Max lifting weight(kg) |
2000 |
Crane boom |
Telescopic 2 boom |
|
|
Working Radius(m) |
5.8 |
Max lifting height(m) |
6.8 |
|
The truck mounted concrete pump is also called concrete pump, concrete pump truck, concrete mixer with pump, portable concrete mixer and pump, etc.
The truck mounted concrete pump we produce are with good quality, best price. We have one small mixer truck with pump. It is one multifunctional truck, which can be used as concrete mixer truck and concrete pump truck. The mixing volume is 0.5 cubic meters and the vertical pump height is 30 meter.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
