dongfeng small double rows 2.5tons truck mounted crane for sale, factory sale best price dongfeng mini truck with crane

Price Negotiable
Price: 20,000-30,000USD/UNIT
MOQ: 1 unit
Delivery Time: 30 days
Brand: Dongfeng
Product Description

dongfeng small double rows 2.5tons truck mounted crane for sale, factory sale best price dongfeng mini truck with crane



Chengli Special Automobile Co., Ltd. is a professional dump truck with crane manufacturer in China, the dump truck with crane for sale is from 2 ton to 32 ton. The drive type of our dump truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.



The truck with crane for sale is also called truck mounted crane,crane truck, truck with crane, etc. The truck with crane for sale is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc





As a professional truck with crane manufacturer in China, the truck with crane for sale is from 2 ton to 160 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane of truck crane can be xcmg, chengli, sany, etc.



If you're interested in our truck mounted crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995



main technical parameters of dongfeng 2tons small cargo truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.

main parameters of hot sale dongfeng 2tons small cargo truck with crane as below
Dongfeng 2ton small cargo truck with crane Main Technical Parameter
Product Model dongfeng Truck with crane for sale Gross Vehicle Weight (kg) 6495
Curb Weight (kg) 3470,3270(Kg) Overall Dimension(mm) 5995×2000×2900(mm)
Lifting Capacity(kg) 2000 Cargo body dimension(mm) 2850×1880,1800×400(mm)
Front/rear suspension(mm) 1032/1663 Max speed(km/h) 90
Axle No. 2 Wheelbase (mm) 3300
Chassis Technical Parameter
Chassis Model EQ1060 Chassis Name Truck Chassis
Chassis Brand Dongfeng Manufacturer Dongfeng Automobile Co., Ltd
Overall Dimension (mm) 5820×1940×2080 Tyre No. 6 with 1 spare tyre
App./ Dep. Angle(º) 19/15 Tyre Spec. 7.00-16
Leaf Spring No. 8/9+5 Front Track (mm) 1506
Fuel Type Diesel Rear Track (mm) 1466
Drive Type 4x2 Brake System Air brake
Steering Type Circulate ball Gear Box 5 speed forward and 1 reverse
Engine Technical Parameter
Engine Model CY4102-C3F Emission Standard Euro III
Displacement ( mL ) 3856 Power (hp/kw) 95hp/70kw
Cylinder No. 4 cylinders in line Engine Type Water cooling, four stroke, inter-cooling charged,
Equipment: 1. Rotational alert lamp on the top of the cabin.
2. Four hydraulic triggers which can be operated independently or simultaneously.
3. Insulated bucket for worker to operation.
4. Telescopic lifting beam, higher lifting height.
5. Imported electro-hydraulic ratio control valve.

Main parameters of XCMG brand 2tons telescopic boom mounted on truck as below
Item Parameters Unit.
Max lifting mass 2100 Kg
Max lifting moment of force 4.2 T.M
Suggested power 9 KW
Hydraulic system max flow 20 L/min
Hydraulic system rated power 16 Mpa
Oil tank volume 25 L
Installation room 850 mm
Rotation degree 360 °full rotation
Working range (m) 2 3.07 5.4 7.73
Lifting mass(kg) 2100.00 1000.00 400.00 255.00



Accoding to the chassis model and customer's requirements,CLW and XCMG brand cranes,2.5t,3.2t,4t,5t,6t,8t,9t,10t,12t,16t,20tstraight cranes and Kunckle Cranescan be selected.

Hydraulic valve is universal in the world on the safe side; three point floating type to protect crossbeam of the truck; all hydraulic pressure and360°turning;new H-shape type; high precise drawn tube;24°tie-in.



More pictures of hot sale dongfeng 2-2.5tons truck with crane as below

Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.

Whatsapp/wechat/Mob.: +86 13329899995;

Skype: truck0011;

QQ: 504873236
