SINO TRUK HOWO 25tons refrigerated truck with THERMO King refeer for sale, best price HOWO 336hp cold room truck for sal
NEW DESGINED 25t refrigerator truck6X4 freezer truck good price HOWO cooling van truck, factory direct sale 6*4 heavy duty cold room truck for sale
Refrigerator wagons/cars/trucks produced by Chengli Special Automobile Co., Ltd
Cover SINOTRUK, DFAC, FAW, FOTON, JAC, JMC brand and range in size and equipment, which can meet different need, such as vegetable transportation, meat transportation, seafood transportation and vaccine transportation.
If you're interested in our HOWO refrigerated truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
Technique Parameters of SINO TRUK HOWO 6*4 refrigerated truck manufactured by Chengli Special Automobile Co., Ltd. as below
|
Description |
SINOTRUK 6x4 Refrigerator Truck |
|
|
Drive Model |
6X4 |
|
|
Vehicle Main Dimensions |
Dimensions(L x W x H)mm |
12000*2500*3980 |
|
Wheel base (mm) |
5825+1350 |
|
|
Overhang (front/rear) (mm) |
1500/3286 |
|
|
Wheel track (front/rear) (mm) |
2022/1830 |
|
|
Approach/Departure angle(°) |
16/10 |
|
|
Weight in KGS |
Curb Weight |
12700 |
|
GVW. |
25000 |
|
|
Max. driving speed(km/h) |
90 |
|
|
Chassis Model |
ZZ1257 |
|
|
Engine |
Model |
WD615.92 |
|
Type |
4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling |
|
|
Horse Power(HP) |
266HP |
|
|
Emission standard |
Euro III |
|
|
Gearbox |
10 forwards & 1 reverse |
|
|
Clutch |
Reinforced diaphragm clutch |
|
|
Steering Gear |
Power steering, hydraulic steering with power assistance |
|
|
Fuel tank (L) |
350 |
|
|
Tire |
11.00-20 tire , 11 pieces including one spare tire |
|
|
Brakes |
dual circuit compressed air brake |
|
|
Van body |
||
|
Van Material |
Double layer FRP(Glass Fiber Reinforced Plastics ) Stainless steel/Color plate can be chosen |
|
|
Thermal insulation |
8CM polyurethane foam |
|
|
Body Overall Dimension |
8300*2300*2500mm |
|
|
Door |
Rear door open, side door is optional |
|
|
Refrigerator unit brand |
China HuaTai Optional:China-Hanxue,America-Carrier/thermo,Korea Dongin, etc |
|
|
Temperature |
-5℃or -18℃ as your choice |
|
Truck refrigerator unit
|
Unit model |
F800 |
||
|
Refrigerator Type |
HUATAI |
||
|
Applicable temperature (℃) |
-18 |
||
|
Applicable volume(m3) |
35 |
||
|
Cooling capacity |
Environmental temperature |
0℃ |
8000 |
|
-18℃ |
4200 |
||
|
Voltage (V) |
DC12V/24V |
||
|
Current (A) |
27/17 |
||
|
compressor |
Displacement (cc/r) |
210 |
|
|
condenser |
Air flow (m3/h) |
- |
|
|
Fan type |
- |
||
|
number |
- |
||
|
evaporator |
Air flow (m3/h) |
- |
|
|
Fan type |
- |
||
|
number |
- |
||
|
refrigerant |
R404A |
||
|
Refrigerant charge amount(Kg) |
3.1-3.2 |
||
|
Defrost type |
Hot gas defrost |
||
|
Dimensions(mm) |
evaporator |
1700×644×230 |
|
|
Condensing utensil |
1565x555x415 |
||
|
Weight(KG) |
evaporator |
54.5 |
|
|
Condensing utensil |
63.2 |
||
|
Remark |
Optional to install for 380v store electric power |
||
More pictures of HOWO 6*4 20ton-25ton cold room truck as below.
SINO TRUK HOWO 6*4 336HP refrigerated truck for sale
howo brand 6*4 47M3 cold room truck for sale
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/Wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
