High quality low price north benz water tank truck with sprinkler for sale, best price CLW brand water carrier truck
High quality low price north benz water tank truck with sprinkler for sale, best price CLW brand water carrier truck
Water tank truck is also called water sprinkling truck, water spraying truck, waterig cart. The carbon steel water tanker truc is mainly used to road sprinkle the road, water the plant, priming the water from fire hydrant by water pump. The stainless steel water trucks which installed with food grade pipeline are mainly used to transport drink water to water shortage aera.
This parameter list is the standard type of truck for this chassis, if you have any other special requires such as you need to add some other components for the truck, please tell us, we will try our best to meet any of your demand.
By the way, You can tell us you buy the truck for what kind of work, and used in what kind of circumstance, so we can give you more suggestions for what kind of truck meet your requirement best.
Water truck is made up of water tank and pump drainaging system.
1, tank, adopts high quality 4mm thickness hot rolled plate, and the double head ends with 5mm hot rolled plates. There is two units of anti-wave plates inside the tank. In order to last the using life, the water tank is with Phosphating coating treatment, and also painted with anticorrosive varnish.
2, Pump drainaging system, chooses Japan technical CLW brand 60-90 model water pump. And the PTO choose to install dongfeng 145 special PTO; the valves choose the high quality CLW brand aluminum alloy ball valves; the pipeline adopts high quality perfect galvanized pipes, etc.
The quality and functions of water trucks
Front spraying: fitted with 360° rotatable straight nozzles controlled by driver cab. The flush width can reach ＞15m.
Rear sprinkling, fitted with 2 rear spraying devices, mainly used to clean the road, make the road clear. When spraying as fan-shaped, the spraying width can reach ＞25m.
High spraying: working platform equipped with water cannon, the spraying range can reach 28m, the water cannon can adjust to heavy rain, moderate rain, drizzle or mist, etc. mainly used for landscaping greening, also sued as fire truck in urgency.
Side sprinkling: install 2 side spraying nozzles behind the truck, mainly used to spray, water, dedusting of the greening, etc.
Self-sucking: install with 2 suction sleeves, one absorber,
Filter device,
If you're interested in our water sprinkling truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com.
The main technical parameters of NORTH-BENZ water tanekr truck manufactured by Chengli Special Automobile Co., Ltd. as below.
|
WATER TANKER TRUCK |
||
|
# |
Descriptions |
Specifications and types |
|
General |
Truck Brand |
Chengliwei (our brand) |
|
Chassis Brand |
North-benze(BEIBEN) |
|
|
Approx. Dimension |
8210*2480*3036 mm |
|
|
GVW./Kerb Wt. |
16000/ 8880 kg |
|
|
Cab |
Cab Capacity |
2 persons' seat |
|
Air Conditioner |
Air Conditioner is optional |
|
|
Chassis |
Drive Type |
4X2,left hand drive |
|
Fuel Type |
Diesel |
|
|
Engine Make & Model |
Weichai engine |
|
|
Power |
180 Ps / 132 KW |
|
|
Emission Standard |
EURO III or Euro IV |
|
|
Brake |
Air Brake |
|
|
Wheelbase/No.of axle |
4100 mm / 3 |
|
|
Tyre Specfication |
10.00-20 10.00R20 |
|
|
Tyre Number |
6 tyres and 1 spare tyre |
|
|
Max Speed |
85 km/h |
|
|
Paint |
Automative metallic paint |
|
|
|
Capacity |
8-15CBM |
|
Structure& Function |
*Equipped with front(rear, side)sprinkler(sprinkling width>14m ) |
|
The above information is for reference only. We can produce according to your needs so, If you have any questions you can contact me at any time.
More pictures of North Benz water tank as below.
More information, please feel free to contact with Ms. Anita
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
