SINO TRUK HOWO 6*4 LHD/RHD 20,000L carbon steel water truck for sale, HOWO 336hp 20m3 water truck for drinkling water
Water Tank Truck is known as the water distributor, multi-function sprinkler, sprinkler, tanker, landscape water. Water sprayer is suitable for all kinds of road surface flush, trees, green belts, lawn planting, roads, construction of factories and mines, high-altitude construction rinse. With water spray, dust, high pressure, low, pesticide spraying, guardrail flushing, etc.
1,Front spraying: fitted with 360° rotatable straight nozzles controlled by driver cab. The flush width can reach ＞15m.
2,Rear sprinkling, fitted with 2 rear spraying devices, mainly used to clean the road, make the road clear. When spraying as fan-shaped, the spraying width can reach ＞25m.
3,High spraying: working platform equipped with water cannon, the spraying range can reach 28m, the water cannon can adjust to heavy rain, moderate rain, drizzle or mist, etc. mainly used for landscaping greening, also sued as fire truck in urgency.
4, Side sprinkling: install 2 side spraying nozzles behind the truck, mainly used to spray, water, dedusting of the greening, etc.
If you're interested in our water truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com.
|
Main specification |
||||||||||
|
Product model and name |
SGZ5250GSSZZ3W water storage tank truck |
|||||||||
|
Gross weight(Kg) |
25000 |
Drive type |
6X4 |
|||||||
|
Payload(Kg) |
14590 |
Overall dimension(mm) |
9950X2500X3000 |
|||||||
|
Curb weight(Kg) |
10280 |
Cab seats |
3 |
|||||||
|
Approach/departure angle(°) |
15/11 |
Front/rear hang(mm) |
1500/2500 |
|||||||
|
Axle No. |
3 |
Wheelbase(mm) |
4600+1350 |
|||||||
|
Axle load(Kg) |
7000/18000 |
Max speed(Km/h) |
90 |
|||||||
|
Chassis specification |
||||||||||
|
Chassis model |
ZZ1257N4647C |
Manufacturer |
China SINOTRUK Group Co.,Ltd |
|||||||
|
Brand name |
SINOTRUK |
Dimension(mm) |
9895X2496X2958 |
|||||||
|
Tyre specification |
11.00-20 18PR |
Tyre No. |
10 |
|||||||
|
Steel spring number |
10/12 |
Front track base(mm) |
2022 |
|||||||
|
Fuel type |
Diesel |
Rear track base(mm) |
1830 |
|||||||
|
Emission standard |
Euro 3 |
Transmission |
10 forward gear,2 reverse gear |
|||||||
|
Cab |
HW flat top,Luxurious interior trim and seats with sleeper and power steering and air condition. |
|||||||||
|
Engine model |
Engine manufacturer |
Displacement(ml) |
Power(Kw) |
|||||||
|
WD615.95E |
China Heavy Duty Truck Group Co.,Ltd |
9726 |
247 |
|||||||
|
Performance |
||||||||||
|
Tank volume(m³) |
18 to 20 |
Tank material |
Carbon steel Q235 |
|||||||
|
Water pump model |
80QZF-60/90N |
Water pump flow(m³/h) |
60 |
|||||||
|
Watering width(M) |
≥14 |
Water cannon range (M) |
≥28 |
|||||||
|
Feature and Application |
||||||||||
|
1).Equipped with high power self-suction water pump that characterized by high-pressure and fast speed suction. 2).Equipped with front, rear and side sprinklers and high position sprinkler, and rear working platform. 3).The water cannon which is installed on the working platform can rotate by 360 degree and the water flow can be adjusted into various rain shape. There are straight shape, heavy rain, moderate rain and drizzle etc. The max range can reach 30M. 4).Equipped with fire coupling, flow valves, filter screen and water level gauge. 5).According to customers’ request, the crane, high working platform and spraying machine also can be equipped. 6).Mainly used for washing on urban roads, watering and greening on trees, green belts and lawn and dust full of construction sites. And also used for drinking water delivery and fire fighting function etc |
||||||||||
