hot sale Dongfeng 3-5cbm compression garbage truck,dongfeng furuika 4*2 LHD 4m3 refuse garbage compactor truck for sale
hot sale Dongfeng 3-5cbm compression garbage truck,dongfeng furuika 4*2 LHD 4m3 refuse garbage compactor truck for sale
Dongfneg furuika 3-5cbm compression garbage truck, adopts dongfeng 1730mm wide dongfeng 1730mm B07 driver cab, 3300mm wheelbase, chaochai 100hp engine, 525 transmission, 2ton front bridge/3.5ton rear bridge, 7.00-16 nylon tyre, etc.
The volume of this dongfeng Furuika compression garbage truck is 3-5cbm, with changeover mechanism, adopting electromechanical integration technology solution, with the help of automatic control system and manual control system of electromechanical integration, through some special devices, such as carriage, precompressor and push shovel, realizing garbage disposed, crushed or crushed, strong draw, forced the garbage into the garbage bucket, and compacted and shirked.
If you're interested in our garbage truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
main parameters of hot sale dongfeng 3-5cubic meters garbage compactor trucks manufactured by Chengli Special Automobile Co., Ltd. as below
|
Dongfeng 3-5cbm compression garbage truck, garbage compacted truck, refuse garbage truck, |
|||
|
Total mass(kg) |
7300 |
Curb mass(kg) |
5160 |
|
Rated mass(kg) |
2010,1945 |
Chassis model |
DFA1070SJ35D6 |
|
Driver cab person |
2,3 |
Max speed(km/h) |
90 |
|
Approach/departure angle(°) |
19/12,19/14 |
Front/rear suspension(mm) |
1032/2138,1032/1988 |
|
Overall dimension(mm) |
6470,6320X2050X2570 |
Cargo body dimension(mm) |
XX |
|
Axles |
2 |
Axle load(kg) |
2920/4380 |
|
Tyre |
7.00-16 14PR,7.00R16 14PR |
Tyre nos. |
6 |
|
Front tread(mm) |
1506,1404,1500,1441 |
Rear tread(mm) |
1466,1458,1520,1500 |
|
Wheelbase(mm) |
3300 |
Springs |
8/9+5,6/8+4,6/6+5 |
|
Emission standard |
GB3847-2005,GB17691-2005Euro Ⅳ |
Fuel type |
Diesel |
|
Engine model |
Manufacturer |
Displacement |
Power |
|
CY4102-CE4F
|
Chaochai |
3856
|
73
|
More pictures of hot sale dongfeng garbage compactor trucks manufactured by Chengli Special Automobile Co., Ltd.
Chengli Special Automobile Co., Ltd. is the leading manufacturer of garbage truck, garbage compactor truck in China since 2004s. With many years 'experience in producing, Chengli Special Automobile Co., Ltd. could supply dongfeng garbage compactor truck, ISUZU garbage truck, forland garbage compactor truck, HOWO garbage compactor truck, etc. More information, please feel free to contact with Ms. Anita Deng.
More pictures of hot sale garbage compactor trucks for sale
