factory direct sale best price dongfeng tianlong 6*4 16cbm vacuum truck for sale, 245hp 16cbm sludge tank truck for sale

Main specifications

Product model,name

dongfeng tianlong 6*4 Sewage suction truck

Gross weight(Kg)

25000

Driving type

6*4

Payload (Kg)

12000

Overall dimension (mm)

9600*2500*3450

Curb weight(Kg)

12805

Cab seats (man)

3

Approach/departure angle (°)

20/15

Front/rear hang(mm)

1460/2440

Axle No.

3

Wheelbase (mm)

4350+1300

Axle load(Kg)

7000/18000(Double axle)

Max speed(Km/h)

90

Chassis specifications

Chassis model

DFL1250A8

Manufacture

Dongfeng motor company

Brand name

Dongfeng

Overall dimension (mm)

9460*2480*3030

Tire specification

11.00-20

Tires No.

10+1

Steel spring number

8/9,8/10

Front track(mm)

1986,2040

Fuel type

Diesel

Rear track(mm)

1860/1860

Emission standard

Euro Ⅲ

Gear box

9 forward

Cab

Engine model

Engine manufacture

Displacement(ml)

Power(Kw)

C260 33

Dongfeng engine co.,ltd

8300

191

Tank body

Tank capacity(m³)

20

Tank material

Q235 carbon steel

Main Characteristic

The truck is equipped with high-powered vacuum suction

pump and high quality hydraulic system. With rear lid of

the tank opened hydraulically, and double cylinders on

both sides of the tank lifting up, the truck can dump the

sewage directly through the rear lid out of the tank.

Characterized by high vacuum, large capacity, high

efficiency and good seal, the truck is widely used.

Full tank pumping time: ≤ 5min; suction width: ≥ 8m.Very

suitable for sucking sewer sediments, such as mud, silt,

stones, bricks and other big objects.
