hot sale best price dongfeng140 long head sewage suction truck, dongfeng 4*2 5cbm vacuum sludge tank truck for sale
hot sale best price dongfeng140 long head sewage suction truck, dongfeng 4*2 5cbm vacuum sludge tank truck for sale
cesspoolage tank trucks manufactured by Chengli Special Automobile Co., Ltd. adopt Wugang GB high quality sheets. The functions of the sludge truck is pumping and delivering feces, mud, bulk oil, etc. liquids. equipped with the leading chengliwei vacuum pump, with feces view window, one discharging open, cleaning device, mobile hanger rod, with 5m length hose, oil separator, anti-overflow valve, metal coating tanker, etc. choosing to install over-flow warming alarm device, double pump, etc.
The cesspoolage truck is widely used to transport liquid manure, slurries, crude oils, and other liquid with small suspending impurity and mainly used in such conditions, including septic tanks, gutters, sewers, toilets, and more. The discharging has high pressure discharging and self-discharging, etc. The time of sucking full the feces tank is ≤6min, the vertical distance is ≥7m, the rated speed is 1450r/min, the flow is 60m3/h..
All of our trucks are approved ISO9001-200 International Quality System Certificate and CCC certificate. And “CLW” brand is the famous brand in China. More infomation, please feel free to contact with Ms. Anita.
If you're interested in our truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
main technical parameters of hot sale DONGFENG LONG HEAD 140 5m3 vacuum truck as below
|
vacuum tank suction tanker truck CLW5100GXWT3 Technical Parameters |
|||
|
Product |
vacuum tank suction tanker truck |
Over dimension |
6965×2470×2850 (mm) |
|
Chassis model |
EQ1102FLJ5 |
Tank dimension |
2950×1400 (mm) |
|
Gross weight |
9950 (kg) |
Approach angle/Departure angle |
34/17 (°) |
|
Rated payload |
4200 (kg) |
Front/rear suspension |
1065/1950 (mm) |
|
Curb weight |
5555 (kg) |
Max speed |
85 (km/h) |
|
Engine |
YC4E140-33 YC6J160-33 |
||
|
Displacement |
4257 6494(ml) |
Power |
105 118(kw) |
|
Manufacturer |
Guangxi Yuchai machinery Co./ Guangxi Yuchai machinery Co |
||
|
Emission standard |
GB3847-2005,GB17691-2005 |
||
|
Axle nos |
2 |
Front tread |
1810 (mm) |
|
Wheelbase |
3950(mm) |
Rear tread |
1800 (mm) |
|
Tire nos |
6 |
Tire specification |
9.00-20 |
|
Fuel type |
diesel |
Leaf spring nos |
9/12+9 |
|
Axle load |
3400/6550 |
Passenger nos |
3 |
|
Remarks |
Equipped with vacuum pump(rating rotate speed=1400r/m, min rotate speed800r/m, max suction lift6m, vacuum500mmHg, clockwise), PTO, shaft, pressure tank, hydraulic parts, vacuum pressure gauge, pipe network, dung windows, hand washing facilities. Time for full suction is 5min. The above information is just for your information. We can manufacture all kinds of sewage suction trucks as per your requirements. And we can try our best to satisfy all demands. |
||
More information, please feel free to contact with Anita.
Whatsapp/wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
