factory direct sale 28ton-30ton coal transporting truck, hot sale best price DONGFENG brand 30tons dump tipper truck
factory direct sale 28ton-30ton coal transporting truck, hot sale best price DONGFENG brand 30tons dump tipper truck
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck and tipper, etc. in China. With many years' development, Chengli Special Automobile Co., Ltd. could 3ton-45ton dump truck, coal dump truck, brick tipper truck, tipper trailer, etc. More information, please feel free to contact with Ms. Anita Deng.
Dump truck is also called as tipper truck or engineering truck, which consist of chassis, hydraulic lifting mechanism, cargo. It can be divided into light duty series, medium duty series, heavy duty series. And it’s widely used in engineering, road construction, sanitation, mines, lime kilns, stones factory, cement stash factory, phosphate fertilizer plant, etc. it can save manpower and reduce labor intensity.
Equipment: the truck is adopted with optimized design hydraulic system and lifting mechanism. It’s lifting is smooth and powerful. The tipper dumping mechanism is using push to enlarge the structure by the former, former top cylinder and middle double cylinder.
If you're interested in our FOTON dump tipper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
1. dump truck adopt with the original maturity chassis to refit.
2. the cargo is made of high quality carbon steel. The cargo thickness can be 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, etc. it’s made in accordance with international standards of manufacturing.
3. the shape can be square bucket, U-shape bucket.
The main technical data of dongfeng 6*4 28ton-30ton dump tipper truck as below.
| Equipment | |||
| Fact loading | 28-30T | One working cycling time | ≤60s |
| Case dimension | 6000*2300*1200mm | Material | carbon steel or stainless steel |
| Side thickness | 5mm | Hermetic style | cover gasket can be choosed |
| Bottom thickness | 6mm | Pullout gate | can equip from rear,side or both |
| Hydraulic cylinder | One Acting | Hermetic operating system | manual control or Hydraulic control |
| Remark:thickness and height of the gate can be adjust to your demand | |||
| Vehicle | |||
| Chassis model | EQ3242 | Engine type | C230-20 |
| Emission standard | Euro3 | Engine power/exhaust | 8300 ml/170 kw |
| Overall dimension | 8385*2480*3320mm | Wheel base | 3900+1300mm |
| F/R track base | 1380/1458mm | F/R overhang | 1245/2005mm |
| GVW | 24950kg | Mini Turning Radius | 16m |
| Mass in working order | 11350kg | Mini Clearance | 240mm |
| Rated loading capacity | 13600kg | Cab passengers | 3 |
| Approach/departure | 32/36° | Max speed | 80km/h |
| Traction system | 6*4 | Number of axles | 3 |
| Tire specification | 10.00-20,11.00-20 | Number of tires | 10 |
| Operation control system | Electrically hydraulic control | Electric system | 24v |
More pictures of dongfeng dump tipper truck as below.
dongfeng 6*4 25tons dump truck for sale
More information, please feel free to contact with Ms. Anita Deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
