ISUZU LHD 4*2 double rows 3ton-5tons mini dump truck for sale, hot sale best price JAPAN brand ISUZU Brand dump tipepr t
ISUZU LHD 4*2 double rows 3ton-5tons mini dump truck for sale, hot sale best price JAPAN brand ISUZU Brand dump tipepr truck
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of dump truck and tipper in China since 2004s. With many years experience in manufacturing, Chengli Special Automobile Co., Ltd. could supply dongfeng brand dump truck, ISUZU tipper, HOWO dump truck, forland dump truck, LHD dump truck and RHD dump truck, etc.
Dump truck is also called as tipper truck or engineering truck, which consist of chassis, hydraulic lifting mechanism, cargo. It can be divided into light duty series, medium duty series, heavy duty series. And it’s widely used in engineering, road construction, sanitation, mines, lime kilns, stones factory, cement stash factory, phosphate fertilizer plant, etc. it can save manpower and reduce labor intensity.
If you're interested in our FOTON dump tipper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995.
Equipment: the truck is adopted with optimized design hydraulic system and lifting mechanism. It’s lifting is smooth and powerful. The tipper dumping mechanism is using push to enlarge the structure by the former, former top cylinder and middle double cylinder.
1. dump truck adopt with the original maturity chassis to refit.
2. the cargo is made of high quality carbon steel. The cargo thickness can be 4mm, 5mm, 6mm, 8mm, 10mm, 12mm, etc. it’s made in accordance with international standards of manufacturing.
3. the shape can be square bucket, U-shape bucket.
And today, let Ms. Anita Deng introduce one of the hot sale ISUZU LHD twin cab mini dump truck as below.
More information, please feel free to cotntact with Ms. Anita Deng.
Whatsapp/wechat: +86 13329899995
Skype: truck0011
QQ: 504873236
More pictures of hot sale ISUZU brand dump tipper truck as below
The main parameters of ISUZU dump truck as below
| Main parameters | |||
| ISUZU Euro 4 LHD mini dump truck | |||
| Total mass(Kg) | 5300 | Capacity | 3ton |
| Rated mass(Kg) | 2085 | Overall dimension(L*W*H)(mm) | 5990×1860×2185 |
| Curb mass(Kg) | 2890 | Cargo body dimension(mm) | 3170×1775×450 |
| Driver cab person | 2+3 | Max speed(km/h) | 98 |
| Approach/departure angle(°) | 24/15 | Front/rear suspension(mm) | 1015/1615 |
| Axle nos. | 2 | Wheelbase(mm) | 3360 |
| Axle load(Kg) | 1970/3330 | Driver cab | ISUZU driver cab with original air-conditioner, power steering and radio |
| Chassis main parameters ISUZU dump truck | |||
| Chassis model | QL10503HWRY | Manufacturer | ISUZU |
| Overall dimension(mm) | 5900×1860×2180 | Tyre nos. | 6 |
| Approach/departure angle(°) | 24/16 | Tyre specification | 7.00-15 10PR, |
| Transmission | ISUZU MSB 5 speed transmission | Brake | Oil brake with vacuum booster pump |
| Steel spring | 8/6+5 | Front tread(mm) | 1385 |
| Fuel type | Diesel | Rear tread(mm) | 1425 |
| Emission standard | Euro 4 | ||
| Engine ISUZU tipper for sale | |||
| Engine model | Manufacturer | Displacement (ml) | Power (Kw) |
| 4JB1CN | ISUZU | 2771 | 72 |
| Cargo body | |||
| Cargo body dimension (L*W*H)(mm) | 3170×1775×450 | Material | High quality carbon steel, 3mm thick side sheet and 4mm thick bottom sheet |
| Dump type | Rear door tipping with double cylinders in the middle | ||
