Economic classical high capacity sewage suction truck, dongfeng brand cheapest price vacuum sewage suction truck
Economic classical high capacity sewage suction truck, dongfeng brand cheapest price 12m3 vacuum sewage suction truck for sale,
Specifications of high capacity sewage suction truck:
high capacity sewage suction truck is called vacuum sewage suction tanker, mainly used in pumping stool,polluted water,floating debris in all kinds of city's municipal sanitation, agricuture,factory,district,etc. It combine the function of self-priming and self-discharging.
Product Notes:
1 The manufacturer is DONGFENG Motor Co., Ltd
2 Tank material: 5mm stainless steel( or carbon steel)
3 High quality vacuum pump, vertical suction lift
4. Factory direct sale
If you're interested in our dongfeng 145 cold room truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Main Parameter of high capacity sewage suction truck:
| Product Name | high capacity sewage suction truck | |
| Cab | Single row cab, two doors, rated passengers 2 or 3 | |
|
Chassis |
Brand | dongfeng |
| Chassis model | EQ5140GLJ | |
| Drive type | 4*2 | |
| Tire | 10.00R20 with 1 spare tire | |
| Tire No. | 6+1(spare) | |
| Braking System | air brake | |
| Transmission | Manual , 6 forward and 1 reverse | |
| Engine | Model | B190 33 |
| fuel type | diesel | |
| Horse Power(kw/hp) | 140kw/190hp | |
| Displacement(ml) | 5900ml | |
| Emission standard | Euro 3/2 | |
|
Dimension & weight |
Overall dimension (L*W*H/mm) | 7650x2480x3200mm |
| Axles No. | 2 | |
| Curb Weight(kg) | 7495 | |
| Max speed(km/h) | 90 | |
| performance parameter | Tank volume(L) | 12m3 |
| Tank material | 5mm carbon steel or stainless steel ,round tank | |
| Vacuum pump | high quality special vacuum pump, vertical suction lift is about 7-10m. | |
| Standard configuration | inspect window, one gravity mouth, cleaning apparatus,5 meter long suction pipe, oil-water separators, overflow valve, etc, | |
| Main function | With self-priming, self-discharging function, with dump function, rear door is controlled by hydraulic, | |
More pictures of hot sale dongfeng brand 12m3 vacuum sewage suction truck as below.
12m3 vacuum sewage suction truck for sale
dongfeng 153 12,000L sewage suction truck for sale
12cubic meters vacuum truck for sale
the main parameters and the description of the truck
a. the sewage suction truck belongs to the medium tonnage special purpose vehicle for wide using.
b. all the tanker materials uses 5mm thickness high quality Wugang sheets. And the capped end adopts 6mm thickness steel sheet one-formed spinning.
The tanker is just a cylinder; the capped end is a half ball shape, the protecting part of the end is about 350mm, and which can avoid tanker and the end not flat for sucking.
c.the tanker volume: 10cbm, adopting Wuagng high quality carbon steel sheets, equipping with big power special vacuum sewage suction pump. And the special parts are made up of vacuum pump, PTO, shaft, water separator, oil separator, multi-way valve, tanker, discharging valve, sewer view window, vacuum pressure gauge, pipelines, hydraulic system, etc. The rear door is operated by the hydraulic switch with self-discharging function. The outlet is shut by pneumatic controlling. The truck also equips with one 5m length hose, with hand cleaning small water tanker.
d. the main advantages and the product description: the sewage suction truck is just suitable for sucking, transport and discharging all kinds liquid or half liquid, such as sewer, septic pool, swill, slops, feces and 8mm stone).
More information, please feel free to contact with Ms. Anita.
Whatsapp/wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
