dongfneg 4*2 RHD 170hp high quality sweeper truck for sale, best price Dongfeng brand RHD 7tons diesel street sweeper
dongfneg 4*2 RHD 170hp high quality sweeper truck for sale, best price Dongfeng brand RHD 7tons diesel street sweeper for sale
dongfeng 145 4*2 RHD road sweeping truck uses middle 4pcs cleaning brushs, and rear installed suction mouth, so the truck cleaning effect is good, and the truck water tanker and garbage box made by SS340 stainless steel; Garbage box and the water tank is an integral structure, water tank in the dustbin garbage box bottom plate bottom pretilt angle up to 12°, easy to dump clean. Garbage box is arranged on the top of the guide groove and a larger area of the filtering net, can fully improve the efficiency of dust removal, so that garbage piles evenly, increase effective capacity, reduced due to a blocked filter and the air resistance.
If you're interested in our sweeper truck, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
main parameters of Dongfeng 145 RHD sweeper truck for sale
| 1 main parameters | ||||
| Product name | CLW5110TSL3road sweeper truck | Remark | ||
| Chassis model | EQ1110 | |||
| Wheelbase | 3950mm | |||
| Front/rear suspension | 1250/1800 (mm) | |||
| Engine model | Truck chassis engine | B170 33 | ||
| Auxiliary engine | B140 | |||
| Output power | Truck chassis engine power | 125KW/170hp | ||
| Auxiliary engine power | 103KW /140hp | |||
| Max Gradient | 30% | |||
| Emission standard | Euro Ⅲ | |||
| Outside-automobile noisy in the accelerating | ≤84dB(A), meeting the noisy of Second stage requirements | |||
| Max speed | 95 km/h | |||
| Approach angle | 19° | |||
| Departure angle | 12° | |||
| Weight | Curb weight | 6800 (Kg) | ||
| Max total weight | 11495kg | |||
| Rated weight | 4500kgs | |||
| Dimension | Overall dimension(L×W×H) | 7000X2480X3000(mm) | ||
| Mini ground clearance | 240mm | |||
| Sucking and sweeping working | Sweeping efficiency | ≥95% | ||
| Max sucking granularity | 120mm | |||
| Sucking-sweeping width | 2.8-3.0 m | |||
| Max sweeping ability | 60000 m2/h | |||
| Extension dimension of dish brush | ≥400 mm | |||
| Sucking disk driving speed | 3-20km/h | |||
| Tanker | Water tank volume | 2.5m³ | ||
| Material | Stainless steel | |||
| Wastes van | Wastes van loading capacity | 6 | ||
| Open angle of the discharging door | ≥45° | |||
| Material | Stainless steel | |||
| Hydraulic system | Type | Open-type, electronic-control | ||
| Main units | Gear pump, hydraulic motor, hydraulic cylinders, solenoid valve, | |||
| System pressure | 16MPa | |||
| Hydraulic oil tank volume | 60L | |||
| Oil temperature | 60 ˚C | |||
| Electronic | Type | DC24V | ||
| voltage | 24V | |||
| Storage battery | 24V(2 sets of 12V in series) | |||
| Water sprinkling system | Main units | Electronic diaphragm pump, water filter, nozzles, | ||
| Sweeping disks device | Type |
4 sets of sweeping disks middle-installed driving by hydraulic motor; The right-front one can work separately, with the function of dodge and repeat working |
||
| Diameter | 850mm | |||
| Angle | ante version:4-6 °; extroversion: 4-7° | |||
| Sucking disk | Tyre | Single sucking, hydraulic-control, spring s | ||
| Sucking diameter | 200mm | |||
| Other device | Rear part | With LED arrow indication light | ||
2, spare parts
| Item | Name | Nos. | Remark |
| 1 | fire fighting hose | 1 | For adding water |
| 2 | fire fighting wrench | 1 | For disassembling fire hydrant |
| 3 | Manual rocker for hydraulic pump | 1 | For manual starting the hydraulic pump |
| 4 | Spare tyre(with the truck) | 1 |
3, spare parts
| Item | Name | Nos. | |
| 1 | Brushing | 80 | |
| 2 | weather-strip of fan | 1 | |
| 3 | weather-strip of rear door | 1 |
4,imported device
| Items | Name | Model | Country |
| 1 | Hydraulic motor | BMR125 | Item |
| 2 | Hydraulic valve | SWH-G02-C4-D2H | Taiwan |
More pictures of hot sale DONGFENG 145 RHD road sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
DONGFENG RHD 170HP road sweeper truck for sale
best price CLW brand 170hp diesel road cleaning vehicle for sale
high quality road brushes for sweeper truck
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat: +86 133298999995
Skype: truck0011
QQ: 504873236
