Factory sale good price FAW brand 4*2 LHD 5m3 garbage compactor truck, HOT SALE! lower price wastes collecting vehicle
FAW 4x2 garbage truck with compressor is also called garbage compactor truck, mainly used in transporting kinds of compressed garbage from garbage compactor station, etc. According to loading type, it is divided into the following categories: side loading refuse compactor truck and rear loading refuse compactor truck.
FAW 4x2 garbage truck with compressor is also called garbage compactor truck, mainly used in transporting kinds of compressed garbage from garbage compactor station, etc.According to loading type, it is divided into the following categories: side loading refuse compactor truck and rear loading refuse compactor truck.
Product Notes:
1. Trash body capacity: 4-5m3
2. Using electronic accelerator;
3. Dozer cylinder have new features for automatic withdrawal;
4. Using Siemens operation circuit;
5. Slider uses the high polymer wear-resistant material;
6. simple structure, convenient operation, high efficiency and high degree of mechanization and labor-saving.
7. Factory direct sale, low price and good quality.
If you're interested in our garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
More pictures of FAW brand 5m3 garbage compactor truck as below
high quality and competitive price FAW brand garbage compactor truck for sale
HOT SALE! lower price FAW brand wastes collecting vehicle
Technical Parameter
| Model | FAW Garbage Truck/FAW Compactor Garbage Truck/FAW Compressed Garbage Truck | ||||
| Driving Model | 4X2/6X4/6X2/8X4/8X6 | ||||
| Vehicle Main Dimensions | (L x W x H)mm | 6150*2494*2800 | |||
| Wheel base (mm) | 3800 | ||||
| Wheel track (front/rear) (mm) | 1500/2665 | ||||
| Approach/Departure angle(°) | 16/10 | ||||
| Weight in KGS | G.V.W. | 16000 | |||
| Curb Weight | 5150 | ||||
| Max. driving speed(km/h) | 80 | ||||
| Engine | Brand | Xichai | |||
| Model | CA4DK1-18E3 | ||||
| Type | 4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling | ||||
| Horse Power | 180(HP) | ||||
| Emission standard | Euro Ⅲ | ||||
| Displacement | 4.78L | ||||
| Max. Output Power | 132kw | ||||
| Gearbox | RTS-11909A 9 forwards& 1 reverse | ||||
| Clutch | Reinforced diaphragm clutch, diameter 430mm | ||||
| Tire | 8.25R16 10.00R20 11.00R20 12.00R22.5All steel radial tire, 6pc including 1 spare tire | ||||
| Brakes | Service brake: dual circuit compressed air brake Parking brake:(emergency brake): spring energy, compressed air operating on rear wheels Auxiliary brake: engine exhaust valve brake | ||||
| Steering Gear | power steering, hydraulic steering with power assistance | ||||
| Garbage Truck Body | |||||
| Volume(M3) | 5CBM 6CBM 7CBM 8CBM 9CBM 10CBM 11CBM 12CBM 13CBM 15CBM 18CBM | ||||
| Material | Q235/Q345/610L/Q700 carbon steel, stainless steel, alloy steeel | ||||
| Equipment | Hermetic dustbin, hydraulic system and operating system | ||||
| Thickness | 4mm 6mm 10mm | ||||
| Uploding cycling time | <60s | ||||
| Loading cycling time | ≤30s | ||||
| Lifting capacity of turnover machanism | ≥800KG | ||||
The technical parameters of FAW brand garbage compacted truck as below
1. Trash body capacity: 4-5m3
2. Using electronic accelerator;
3. Dozer cylinder have new features for automatic withdrawal;
4. Using Siemens operation circuit;
5. Slider uses the high polymer wear-resistant material;
6. simple structure, convenient operation, high efficiency and high degree of mechanization and labor-saving.
7. Factory direct sale, low price and good quality.
Our CLW brand garbage compactor truck is constructed with 12# low alloy steel 4mm, 5mm, 10mm steel. The body is fitred on the chassis by the truck beam. The body floor is fully sealed. All the sewage can go directly into the sewage tank, so as no to corrode the body and chassis. Moreover, it can also prevent the sewage leakage while the truck is driving on the road and avoid the secondary pollution.
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype: truck0011
QQ: 504873236
