Wholesale bottom price customized dongfeng 4*2 RHD 190hp Euro 3 14m3 compression garbage truck, garbage compactor truck
Wholesale customized dongfeng 4*2 RHD 190hp Euro 314m3 compression garbage truck for sale, Factory sale bottom price 14cbm garbage compactor truck
CLW Brand garbage compactor trucks are also called rear loader garbage truck, wastes collecting vehicles, etc. This kind of garbage truck is a kind of special purpose vehicle, mainly used for collecting, transporting and discharging bagged wastes, barreled wastes, bulk household wastes in towns and cities, etc.The wastes is pressured and pushed into the wastes van by the truck mounted wastes propeller (also called negative pressure mechanism), so that making the wastes distributing into the tank evenly and higher density and till full.The collecting and transporting way of the garbage compactor truck adopts widely all over the world. The function of the entire special device adopts the truck engine as power, realizing by hydraulic mechanism manual or electronic control.The wastes van and the loader, which is also called wastes tan and sewer tank, adopting high quality carbon steel with full-sealed welding structure, with the advantages of high strength, light weight, non second pollution, etc.
And the volume of dongfeng 4*2 RHD garbage compactor truck is 12cbm-14cbm, adopting high quality China standard light duty steel, solid arc-shape box body of strengthen beam and steel plate welded.
Operation way of compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
1, PLC control system;
2, loading and discharging way: rear loading wastes bins mechanism;
3, compacting way: Bi-directional compression; wastes compacting density≥0.8T/m³; 4, one working circle time for loading and discharging ≤30s;
5, max compressing force≥150KN; max passing force≥180KN.
if you're interested in our diesel garbage compactor truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
main technical parameters of Dongfeng 4*2 RHD 190hp diesel Euro 3 14m3 garbage compactor truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Truck model | CLW5140ZYST3 |
| Product name | 153 garbage compactor truck |
| Wheelbase(mm) | 4500/4700mm |
| Overall dimension(L*W*H)(mm) | 8520*2490*3350 |
| Chassis model | EQ1141 |
| Curb mass(kg) | 8795kg |
| Rated mass(kg) | 5500kg |
| Total mass (kg) | 14490kg |
| Upper parts main part parameters | ||
| Working condition | Main parameters | Remark |
| Van Part dimension | 4330*2400*1850 | Common 13.5cbm |
| Van part material | Side sheet 4mm, bottom sheet 5mm | common |
| Drain tanker | 200L | |
| Filter volume | 1.2cbm | |
| Filling time | 8-10s | |
| Filling circling time | 50-60s/time | |
| Discharging way | Flat push type self-discharging, | |
| Discharging time | 30-40s | |
| Hydraulic system pressure | 16MPa | |
| Control way | Electric control with manual control | |
| reduction ratio | 1: 0.6-0.8 | |
the main devices parameters
| Hydraulic pump | 563 | 1 |
| Multi-way valves | DL-15B-6 | 1 |
| Tilting plate oil cylinder | 80/45-410*180 | 2 |
| Negative pressure oil cylinder | 80/45-390*470 | 2 |
| Lift cylinder | 80/45-900*660 | 2 |
| Shave cylinder | 80/45-655*445 | 2 |
| Sliding board cylinder | 100/45-1375*1100 | 2 |
| Push pedal cylinder | YSTB-1150*2170-(Ⅲ) | 1 |
| Integrated air valve | 1 | |
| Electromagnetic valve | UZCT-115/24V | 2 |
| Limit switch | JXL19-111 | 2 |
More pictures of 15cbm compacted garbage truck manufactured by Chengli Special Automobile Co., Ltd. as below.
High quality and competitive price DONGFENG 4*2 LHD 190hp diesel garbage compactor truck for sale
simple drawing pictures of CLW brand compacted garbage truck for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of garbage trucks in China since 2004s. With many years' experience in developing, Chengli Special Automobile Co., Ltd. could supply garbage compactor truck, refuse garbage truck, swing arm garbage truck, skid loader garbage truck, side loader garbage truck, sealed garbage truck, dump garbage truck, etc. More information, please feel free to contact Ms. Anita Deng.
Whatsapp/Wechat/Mob.: +86 13329899995
Skype:truck0011
QQ: 504873236
