best price mini Chang'an 4*2 LHD gasoline road sweeper truck for Oman, HOT SALE! new gasoline street sweeper vehicle
best price mini Chang'an 4*2 LHD gasoline road sweeper truck for Oman, HOT SALE! gasoline street sweeper vehicle
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper trucks in China. With many years’ development, we Chengli Special Automobile Co., Ltd. could offer ISUZU road sweeper truck, forland street sweeper truck, dongfeng brand road cleaning vehicle, JMC brand road sweeping vehicle, JAC brand street sweeper, FAW brand street sweeping vehicle, etc.
The road sweeping vehicle is installed with middle 4pcs cleaning brushes, and rear part with suction mouth, so the truck cleaning effect is good and the truck water tanker and garbage box made by SS340 stainless steel.Garbage box and the water tank is an integral structure, water tank in the dustbin garbage box bottom plate bottom pretilt angle up to 12°, easy to dump clean.Garbage box is arranged on the top of the guide groove and a larger area of the filtering net, can fully improve the efficiency of dust removal, so that garbage piles evenly, increase effective capacity, reduced due to a blocked filter and the air resistance.
More information, please feel free to contact with Ms. Anita.
Website: www.trucksinchina.com
Whatsapp/Wechat/Mob.: +86 13329899995
QQ: 504873236
Today, we will introduce Chang'an 4*2 LHD gasoline road sweeping vehicle manufactured by Chengli Special Automobile Co., Ltd. as below
| Main technical parameters | |||
| Product name | Chang’an road sweeping truck for slae | ||
| Total mass(Kg) | 2840 | Overall dimension(L*W*H)(mm) | 4650,5100×1750×2250 |
| Rated mass(Kg) | 360 | Curb mass(Kg) | 2350 |
| Driver cab seated person | 2 | Front/rear suspension(mm) | 635/1315,635/1475 |
| Approach/departure angle(°) | 40/18 | wheelbase(mm) | 2700 |
| Alxe nos. | 2 | Max speed(Km/h) | 90 |
| Axle load(Kg) | 1420/1420 | Emission standard | Euro Ⅴ |
| Chassis main parameters | |||
| Truck chassis | SC1031GDD52 | Tires nos. | 4 |
| Approach/departure angle(°) | 40/25 | Tire specification | 165R14LT |
| Steel spring | -/5,4/5 | Front tread(mm) | 1360,1372 |
| Fuel type | gasoline | Rear tread(mm) | 1300 |
| Engine model | Manufacturer | displacement(ml) | power(KW) |
| DK12-10 | Xiaokang power | 1240 | 65 |
| Sweeping devices |
1, the volume of the stainless steel is 0.8cbm; while the volume of the stainless steel dust hopper is 1.7cbm. 2, middle-installed sucking disk, 3, Schneider control switch 4, LN 31hp auxiliary engine 5, stainless steel dust hopper 6, HI-PRESSURE electromagnetic valve unit. 7, infinite variable speed automatic clutch, 8, maintenance-free centrifugal fan, 9, high precision filter system for the dust hopper(max up to 0.3micronmeter), 10, imported sentinel valve, 11, tail with LED arrow lamp, 12, manual pump emergency system 13, tail with mist spraying and wetting system |
||
More pictures of Chang'an street sweepe truck as below
Customized Chang'an gasoline road sweeper truck for sale
high quality and competitive price Chang'an4*2 LHD gasoline street sweeper truck
Chang’an 4*2 LHD gasoline smallest road sweeping truck, adopts Chang’an 4*2 LHD single row driver cab, electric EPS power steering, Chongqing power DK12-10 Euro 5 gasoline 88hp engine, 5 speed gearbox, front-disc and rear drum braking, 165R15 vacuum tires, etc.
There are 4 sets middle-installed sweeping plates, SANYO motor, LN 31hp auxiliary engine, Schneider controlling switches, HI-PRESSURE solenoid valves, Continuously variable automatic clutch, maintenance-free centrifugal fan, stainless steel dust tank, Polaris brand Electronic pump, dust tank lifting and tipping, rear part with arrow LED lamp, Manual pump emergency system ,etc.
