factory sale best price customized FAW 4*2 RHD diesel road washing and sweeping vehicle, road cleaning truck for sale
Street sweeping washer vehicle is with the functions of sweeping and cleaning road surface, sweeping and washing curb,low pressure washing and spraying mist dedusting, etc.
There are 9 operation models to choose, “full sweeping-washing”, left sweeping-washing”, “right sweeping-washing”, “fullsweeping”, “left sweeping”, “right sweeping”, “full washing”, “left washing”, right washing”, etc.
1, the CLW brand sweeping washing truck, adopts layout of front with clean water tank and rear with sewer tank, Semi closed Auxiliary engine cabin, left and right double side door, etc.
2, the ground pressure of the side sweeping brushes system adopts Spring adjustable model; adjusting the ground pressure of the sweeping brushes according to the road condition to reduce the abrasion of the sweeping brushes; the sweeping brushes can be adjusted low-high speed.
3, the high pressure water pump and nozzles adopts German brand; water pump is with stainless steel pump head, and the pressure up to 160Bar, max flow is 154L/min. Good road cleaning effect.
4, the hydraulic valves adopts solenoid diectional valve arranged in good order, easy to maintain; the hydraulic motor adopts Italian brand. The whole truck is with reliable hydraulic system, flexible working, etc.
5, the road sweeping washing vehicle adopts the particular centrifugal blower, and the blowing up to 12000m3/h; the blades of the blower adopting special steel, which is not easy to abrase.
6, the special side sweeping brushes anti-collision mechanism can protect the side sweeping brushes and avoiding the flushing and washing device collide the road.
7, the high pressure road cleaning vehicle adopts the working way of sweeping first then flushing sweeping, then sucking; cleaning, flushing, sucking the wastes and sewer at one time . After working, the road is without dust and water.
8, high pressure water line is installed with ant freezing water coupling, avoiding the water line freezed in winter.
9, the Key units of the electronics, adopts high quality imported ones; Operation controlling is with PLC one-key operation, realizing 9 kinds of working modes. The truck can be operated at the driver cab, easy to operate.
10, the road sweeping cleaning vehicle adopts cylinders driving’ electronic automatically control the clutch to ensure the auxiliary engine starting-stopping no load, lasting the lifetime.
11, the truck is with the self-return flushing reel and high pressure and big flow flushing nozzle, flushing heavily certain greasy dirt and also flushing and cleaning the advertisement billboards, etc.
12, the truck is with voice alarm device, realizing the function of Fault self diagnosis. And the also with anti overflow –low water level alarm device, etc.
13, the high pressure road sweeping washing vehicle is with cameral for the working and backing.
If you're interested in our FAW Brand RHD road sweeping and washing truck (4m3 water tank+4m3 dust tank), please kindly send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
Today, we will introduce 2018s new designed FAW brand 4*2 RHD 130hp diesel road sweeping washer customized for client from Bangladesh as below.
FAW brand 4*2 RHD 130hp diesel road sweeping and washing truck for sale
High quality and competitive price FAW brand road washing and sweeping truck for sale
HOT SALE! FAW brand street cleaning and washing truck
main technical parameters of FAW brand 4*2 RHD road sweeping and washing trucks manufactured by Chengli Special Automobile Co., Ltd. as below.
| Item | Main parameters | ||
| Truck name | FAW brand 4*2 RHD road sweeping and washing truck for sale | ||
| Truck chassis | CA1083P40K2L1EYA84 | ||
| Emission standard | Euro 3 | ||
| Engine | Main engine | Truck engine model and manufacturer | YC4D130-33 Yuchai diesel engine |
| Power (kw) | 96 | ||
| Horsepower (ps) | 130 | ||
| Displacement (ml) | 4214 | ||
| Auxiliary engine | Auxiliary engine Model | JX493 Jiangxi wushiling diesel engine |
|
| Rated power (kw) | 102 | ||
| Horsepower (ps) | 140 | ||
| Displacement(ml) | 3200 | ||
| Fuel type | Diesel | ||
| Basic parameters | Overall dimension(L*W*H)(mm) | 7000*2180*2500 | |
| Wheelbase (mm) | 3860 | ||
| Tires specification | 8.25R16 | ||
| Tires nos. | 7(6+1) | ||
| tread | Front (mm) | 1634 | |
| Rear (mm) | 1590 | ||
| seated person | 3 | ||
| Front/rear suspension(mm) | 1150/1800 | ||
| Approach angle | 22 | ||
| Departure angle | 20 | ||
| Mini Ground clearance (mm) | 200 | ||
| Rated mass(kg) | 4210 | ||
| Curb mass(kg) | 7045 | ||
| Max total mass(kg) | 11450 | ||
Special devices |
Wastes van volume( m3 ) | 4(stainless steel) | ||
| Water tank volume( m3 ) | 4(stainless steel) | |||
| sweeping width(mm) | 2800-3200 | |||
| sweeping speed(km/h) | 3-15 | |||
| Cleaning speed(km/h) | 15-20 | |||
| max sweeping ability(m2/h) | 48000 | |||
| Sucking capacity | density(g/cm3) | 2.0 | ||
| Mass (kg) | 1.5 | |||
| Sucking granularity (mm) | ≥100 | |||
| Garbage tank dump corner | ≥45° | |||
| Cleaning efficiency | ≥96% | |||
| Dust system | Water-spraying | Low-pressure spraying | ||
| Main components | Germany imported high pressure pump, water filter, pipelines, stainless steel spray racks, high pressure nozzles, etc. | |||
| High pressure water pump | Germany imported | |||
| Installation position | Cleaning and dedusting | Front Left-right sweeping disks | ||
| Sucking and dedusting | Suction cup inside the suction port |
|||
| Control type | Electronic control, one-button operation |
|||
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of road sweeper trucks in China. With many years’ development, we Chengli Special Automobile Co., Ltd. could offer ISUZU road sweeper truck, forland street sweeper truck, dongfeng brand road cleaning vehicle, JMC brand road sweeping vehicle, JAC brand street sweeper, FAW brand street sweeping vehicle, etc. More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat:+86 13329899995
Skype: truck0011
QQ: 504873236
