HOT SALE! new ISUZU Brand road washing sweeper vehicle for sale, Best price ISUZU diesel street sweeping truck for sale
HOT SALE! new ISUZU Brand road washing sweeper vehicle for sale, Best price ISUZU street sweeping truck for sale
The standard devices of dongfeng street washing sweeper truck are as below.
2 middle-installed sweeping disks, CUMMINS 170hp auxiliary engine, Taiwan hydraulic valves, dali motor, German high pressure water pump(front-spraying/side spraying/middle-spraying/rear spraying(stainless steel sprayers)/side flushing-washing guns/dust tank self-cleaning device); universal high pressure roadside cleaning, Taiwan hydraulic valves units, weilong low-pressure pump(front-flushing), 4mm thickness stainless steel dust tank+ 4mm stainless steel water tank, stainless steel high pressure pipeline, German controller, rear part arrow light; oil, dust tank, and water tank are with anti-overflow or low alarm device; Reversing and washing state monitor; Anti-dumping garbage rollover protection and Overhaul safety protection;
20m high pressure flushing reel; Brush arm rotation mechanism uses German imported high-tech wear-resistant engineering spacer, butter-free; Integrated motion controller with one-button computer control.
The chosen part for the road sweeper truck is as below.
1, trash self-cleaning function is optional.
2, Reversing monitoring function is optional
3, front-flashing and rear sprinkling is optional
If you're interested in our road sweeper trucks, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
More pictures of ISUZU brand road washing sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and best price ISUZU brand road washing sweeper truck for sale
Customized ISUZU brand road washing sweeper truck for sale
Main technical parameters of ISUZU Brand road washing sweeper truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Item | Main parameters | ||
| Truck brand | ISUZU brand | ||
| Truck model | CLW5100TXSQ5 road washing sweeper for sale | ||
| Truck chassis | QL1100A8LAY | ||
| Emission standard | Euro Ⅴ | ||
| Engine | Truck engine | Truck engine |
4HK1-TC51 qinglingwushiling
|
| Power (kw) | 141 | ||
| Horsepower (ps) | 191 | ||
| displacement(ml) | 5193 | ||
| Auxiliary engine | Engine model | B140 Dongfeng Cummins | |
| power(kw) | 102 | ||
| horsepower(ps) | 140 | ||
| Displacement (ml) | 3200 | ||
| Fuel type | Diesel | ||
| Basic parameters | Overall dimension(L*W*H) mm | 7430*2290*2750 | |
| Wheelbase (mm) | 4175 | ||
| Tires specification | 8.25R20 14PR | ||
| Tire now. | 6+1 | ||
| tread | Front tread(mm) | 1680 | |
| Rear read(mm) | 1650 | ||
| Seated person | 3 | ||
| Front/rear suspension (mm) | 1110/2145 | ||
| Approach angle | 20° | ||
| Departure angle | 11° | ||
| Ground clearance (mm) | 320 | ||
| Rated mass(kg) | 1500 | ||
| Curb mass(kg) | 8360 | ||
| Total mass(kg) | 10055 | ||
|
Special parameters |
Dust tank volume( m3 ) | 6(stainless steel material) | ||||
| Clean water tank volume( m3 ) | 5(stainless steel material) | |||||
| Sweeping width (mm) | 2800-3200 | |||||
| Sweeping speed (km/h) | 3-15 | |||||
| Working speed (km/h) | 15-20 | |||||
| Max cleaning ability (m2/h) | 48000 | |||||
| Suction capacity | Density (g/cm3) | 2.0 | ||||
| Mass (kg) | 1.5 | |||||
| Extraction granularity (mm) | ≥100 | |||||
| Dust tank dumping angle | ≥45° | |||||
| Cleaning efficiency | ≥96% | |||||
| Driving parameters | Driving type | 4×2 | ||||
| Suspension type | Steel spring | |||||
| Steel spring no. (front/rear) | 8/10+7 | |||||
| Braking type | Double loop pressure brake, drum type | |||||
| Braking distance (full load30km/h) | ≤10m | |||||
| Max speed(km/h) | 99 | |||||
| mini turning radius (m) | 8 | |||||
| Max Climbing slope | ≥30％ | |||||
| Clutch system | Single dry diaphragm spring clutch,hydraulic control | |||||
| Transmission system | Mechanical 5-speed transmission with Synchronizer, manual | |||||
| Engine oil consumption | Driving (L/100km) | Sweeping (L/h) | Sweeping (L/10000m2) | |||
| ≤12 | ≤6 | ≤3 | ||||
| Dust system | Spraying type | Low pressure fog | ||||
| Main component composition | German imported high pressure pump water filter line stainless steel nozzle nozzle, etc.. | |||||
| High pressure pump | GERMAN IMPORTED | |||||
| Installation position | Clean up the dust | Left-right front sweeping disc | ||||
| Sucking dust and dedust | Suction cup in the suction vent | |||||
| Control type | Electronic control, one-click operation | |||||
