HOT SALE! New brand dongfeng double cabs 2tons telescopic boom mounted on truck, best price truck with crane
Chengli Special Automobile Co., Ltd. is a professional dump truck with crane manufacturer in China, the dump truck with crane for sale is from 2 ton to 32 ton. The drive type of our dump truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
The truck with crane for sale is also called truck mounted crane,crane truck, truck with crane, etc. The truck with crane for sale is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional truck with crane manufacturer in China, the truck with crane for sale is from 2 ton to 160 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc. The crane of truck crane can be xcmg, chengli, sany, etc.
The features of CLW Brand Crane boom manufactured by Chengli Special Automobile Co., Ltd. as below.
Single cyliner synchronization guy cable technology make work efficiency more higher
The more symmetrical center design of pentagon hexagon boom make it has bigger anti-bending capacity.
The work is more safety after ftted with over wind alarm equipment
The integer lifting winch improved the work efficiency greatly and prolonged work life of hydraulic system
Float three-point bridge structure design can lower the accessional stress on the chassis when traveling.
Anti-slewing impulse equipment that make vehicle running safely
The rear leg to ensure the safety during the lifting
The operation can be done on the ground or in the air, the operator can see the cargo loading condition during his operation.
If you're interested in our truck mounted crane, please send email to truck0011@163.com or talk to Anita byWhatsapp/Wechat: +86 13329899995.
Website: www.trucksinchina.com
More pictures of dongfeng double cabs 4*2 LHD 2tons telescopic truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
high quality and competitive price dongfeng brand 2tons telescopic boom mounted on truck for sale
HOT SALE! CLW brand 2tons telescopic boom mounted on cargo truck for sale
main technical parameters of dongfeng double cabs LHD 2tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name | Dongfeng double cabs LHD 2 tons telescopic rane boom mounted on truck for sale (CLW5050JSQ3) | |
| Chassis type | EQ1050NJ20D3 | |
| Parameters | Overall dimension length/width/height (mm) | 5995×2000×2900 |
| Cargo body dimension (L*W*H)(mm) | 2850×1880,1800×400 | |
| GVW(kg) | 5495 (Kg) | |
| Kerb Mass(kg) | 3270 (Kg) | |
| Rated mass(kg) | 1900(Kg) | |
| Approach angle/ Departure angle(mm) | 19/15 (°) | |
| Front suspension/rear suspension(mm) | 1032/1663 | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | CY4100Q |
| Displacement/Power(kw) | 3856ml/70KW/95hp | |
| Manufacturer | Dongfeng chaochai Engine Co.,Ltd | |
| Type | 4-in-line inter-cooling; intercooling | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3300 | |
| Tread(front/rear) | 1404,1506/1458,1466 (mm) | |
| Transmission | 5 forward gear,1 reverse gear, mechanical transmission | |
| Braking system | Air braking | |
| Cab | Dongfeng single row driver cab | |
| Number of spring axle(front/rear) | 8/9+5,6/8+4 | |
| Tire Type | 7.00-16 | |
| Air-condition | Choose to fix | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 2850×1880,1800×400 |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 3mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 2T 2/3 sections folded crane boom | |
| The color of the whole truck is upon request. | ||
