customized dongfeng 140 long head 4tons telescopic crane boom mounted on truck for sale, 4tons cargo truck with crane
The crane with truck is also called crane truck, truck with crane, truck mounted crane, etc. The truck with crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional truck mount crane manufacturer in China, the crane for truck we manufacture is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane for sale are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Dongfeng 140 long head 4tons truck with crane adopts dongfeng brand long head single row driver cab, 4700mm wheelbase, Yuchai YC4E140-33 140hp diesel engine, 5 speed manual gearbox, 2.8tons front axle/8tons rear axle, 9.00-20 nylon tires*6, etc.
Choose to install CLW brand high quality 4tons telescopic crane boom mounted on truck. The overall dimension of dongfeng long head 140 truck with crane is 8000×2470×3350,3300,3150(mm), the cargo body dimension(L*W*H): 4500×2274×550(mm).
More pictures of dongfeng 140 long head 4tons truck with crane as below.
specification of dongfeng 140 longhead 4tons truck with crane manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name | Dongfeng brand 140 long head 4*2 LHD 4ton truck with crane(telescopic boom) | |
| Truck chassis | EQ1102FLJ6 | |
| Parameters | Overall dimension length/width/height (mm) | 8000×2470×3350,3300,3150 |
| Cargo body dimension (L*W*H)(mm) | 4500×2274×550 | |
| GVW(kg) | 10495 (Kg) | |
| curb Mass(kg) | 6450 (Kg) | |
| Rated mass(kg) | 3850 (Kg) | |
| Approach angle/ Departure angle(mm) | 34/16 (°) | |
| Front suspension/rear suspension(mm) | 1065/2235 (mm) | |
| Fuel Type | diesel | |
| Max Speed | 80 | |
| Engine | Type | YC4E140-33 |
| Displacement/Power(kw) | 4257ml/105KW/140hp; | |
| Manufacturer | Yuchai engine; | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 4700 | |
| Tread(front/rear) | 1810/1800 | |
| Transmission | 5 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | Dongfeng long head driver cab | |
| Number of spring axle(front/rear) | 9/11+8 | |
| Tire Type | 9.00-20-12 | |
| Air-condition | Choose to fix | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 4500×2274×550 (mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 4ton telescopic boom | |
| Max lifting mass | 4000kgs | |
| Sections | 3/4 | |
| Working radius | 7.9m/11m | |
| Lifting height | 9.9m/13m | |
| Rotation degree | ±360°full rotation, full hydraulic | |
