Dongfeng tianlong 8*4 350hp Euro 5 16tons telescopic crane mounted on truck for sale, cargo truck with crane for sale
Dongfeng tianlong 8*4 LHD 350hp Euro 5 16tons telescopic crane boom mounted on truck for sale, factory sale best price cargo truck with crane for sale
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
The truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
HOT SALE! Dongfeng brand 16tons telescopic crane boom mounted on truck
Customized dongfeng tianlong 8*4 LHD 16tons telescopic truck with crane adopts dongfeng tianlong 8*4 LHD one row and a half driver cab, 1850+4600+1400mm wheelbase, 5tons front axle/10tons single grade reduced double rear axles, 11.00R20 rail tires, fastgear 12 speed manual gearbox, DDi75S350-50 350hp diesel Euro 5 engine, original air conditioner, etc.
main technical parameters of dongfeng tianlong 16tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name | Dongfeng 8*4 LHD 16tons telescopic boom mounted on truck for sale | |
| Chassis type | DFH1310A1 | |
| Parameters | Overall dimension length/width/height (mm) | 12000×2500,2550×3680,3700,3810,3910 |
| Cargo body dimension (L*W*H)(mm) | 8400×2300,2400,2450×600,800 | |
| GVW(kg) | 31000 (Kg) | |
| Kerb Mass(kg) | 18400 (Kg) | |
| Rated mass(kg) | 12470 (Kg) | |
| Approach angle/ Departure angle(mm) | 22/10 (°) | |
| Front suspension/rear suspension(mm) | 1500/2650, | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | DDi75S350-50 |
| Displacement/Power(kw) | 7530ml/257KW/350hp | |
| Chassis | Drive Type | 8*4 |
| Wheelbase(mm) | 1850+4600+1400mm | |
| Front tread | 2040/2040 (mm) | |
| Rear tread | 1860/1860 | |
| Transmission | Fastgear 12 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | Dongfeng tianlong one and a half driver cab | |
| Number of spring axle(front/rear) | 8/9+7 | |
| Tire Type | 1100R20*12 | |
| Air-condition | Original air conditioner | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 8400×2300,2400,2450×600,800 |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 16T 5 sections telescopic crane boom | |
| Crane boom lifting height | 21.5m | |
| Crane boom working radius | 19.5m | |
| Rotation | Full hydraulic, full rotation | |
| The color of the whole truck is upon request. | ||
| Product name | Dongfeng 8*4 LHD 18tons telescopic boom mounted on truck for sale | |
| Chassis type | DFH1310A1 | |
| Parameters | Overall dimension length/width/height (mm) | 12000×2500,2550×3680,3700,3810,3910 |
| Cargo body dimension (L*W*H)(mm) | 8400×2300,2400,2450×600,800 | |
| GVW(kg) | 31000 (Kg) | |
| Kerb Mass(kg) | 18400 (Kg) | |
| Rated mass(kg) | 12470 (Kg) | |
| Approach angle/ Departure angle(mm) | 22/10 (°) | |
| Front suspension/rear suspension(mm) | 1500/2650, | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | DDi75S350-50 |
| Displacement/Power(kw) | 7530ml/257KW/350hp | |
| Chassis | Drive Type | 8*4 |
| Wheelbase(mm) | 1850+4600+1400mm | |
| Front tread | 2040/2040 (mm) | |
| Rear tread | 1860/1860 | |
| Transmission | Fastgear 12 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | Dongfeng tianlong one and a half driver cab | |
| Number of spring axle(front/rear) | 8/9+7 | |
| Tire Type | 1100R20*12 | |
| Air-condition | Original air conditioner | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 8400×2300,2400,2450×600,800 |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 18T 6 sections telescopic crane boom | |
| Crane boom lifting height | 21.5m | |
| Crane boom working radius | 19.5m | |
| Rotation | Full hydraulic, full rotation | |
| The color of the whole truck is upon request. | ||
More information, please contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Email ID: truck0011@163.com; anitadeng1027@hotmail.com
QQ: 504873236
