customized SINO TRUK HOMAN 130hp Euro 5 diesel 4tons cargo truck with crane for sale, telescopic crane boom on truck
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck with crane in China. With many years’development, Chengli Special Automobile Co., Ltd. could manufacture and export 4*2 truck with crane, 4*4 cargo truck with crane, 6*4 dump truck with crane, 8*4 truck mounted crane, etc. And our CLW brand truck mounted crane are from 1tons to 20tons and heavy duty.100tons/150tons/200tons crane truck, etc. More information, please feel free to contact with Ms. Anita.
The truck mounted concrete pump is also called concrete pump, concrete pump truck, concrete mixer with pump, portable concrete mixer and pump, etc. The truck mounted concrete pump we produce are with good quality, best price. We have one small mixer truck with pump. It is one multifunctional truck, which can be used as concrete mixer truck and concrete pump truck. The mixing volume is 0.5 cubic meters and the vertical pump height is 30 meter.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc.
If you're interested in our truck mounted crane, please feel free to send email to truck0011@163.com or talk to Anita directly by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
More pictures of SINO TRUK HOMAN 4tons telescopic crane mounted on truck with 3.4m length cargo body as below.
The specification of SINO TRUK HOMAN 4*2 LHD 4ton truck with crane(telescopic boom) as below.
| Product name | SINO TRUK HOMAN 4*2 LHD 4ton truck with crane(telescopic boom) | |
| Truck chassis | ZZ1048D17EB1 | |
| Parameters | Overall dimension length/width/height (mm) | 5995×2520,2350,2250×3200,2900,2700,3470 (mm) |
| Cargo body dimension (L*W*H)(mm) | 3450,3260×2400,2300,2150×600,550,400 (mm) | |
| GVW(kg) | 4495 (Kg) | |
| curb Mass(kg) | 3805 (Kg) | |
| Rated mass(kg) | 495 (Kg) | |
| Approach angle/ Departure angle(mm) | 20/16 (°) | |
| Front suspension/rear suspension(mm) | 1175/1520 (mm) | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | YN38CRE1 |
| Displacement/Power(kw) | 3760ml/70KW/95hp; | |
| Manufacturer | Yunnei engine; | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3300 | |
| Tread(front/rear) | 1825/1615 | |
| Transmission | Xiao 8 speed transmission, manual | |
| Braking system | Air braking | |
| Cab | 2080mm single row driver cab | |
| Number of spring axle(front/rear) | 3/5+3 | |
| Tire Type | 825R16 | |
| Air-condition | Choose to fix | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 3450,3260×2400,2300,2150×600,550,400 (mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 4ton 4 sections telescopic crne boom | |
| Max lifting mass | 4000kgs | |
| Sections | 4 | |
| Working radius | 11m | |
| Lifting height | 13m | |
| Rotation degree | ±360°full rotation, full hydraulic | |
More information, please feel free to contact with Ms. Anita.
Whatsapp/Wechat/Mob.: +86 13329899995
Email: truck0011@163com; anitadeng1027@hotmail.com
QQ: 504873236
