cheapest SINO TRUK WANGPAI 4*2 LHD 5tons telescopic crane boom mounted on truck for sale, truck mounted with crane
cheapest price SINO TRUK WANGPAI brand 4*2 LHD 5tons telescopic crane boom mounted on truck for sale, hot sale cargo truck mounted with crane
Truck crane ,also called boom truck crane,mobile truck crane , truck mounted crane , hydraulic folding truck crane,telescopic straight boom crane,truck with crane , crane lorry,hydraulic arm crane for trucks,pickup truck mounted crane,light truck with crane,folding arm hydraulic lift platform,hydraulic crane telescopic boom,mobile crane price ,self loader truck with boom crane,new forland lorry truck mounted crane,telescopic boom truck mounted crane,flatbed knuckle boom truck crane,6 wheelers truck with crane boom truck cranes sale,etc.
A crane mounted on a truck carrier provides the mobility for this type of crane. This crane gas twp parts: the carrierm which offer to be offered as the lower; while the lifting component which includes the boom refered as the upper. These are mated tog through a turnable, allowing the upper to swing from side to side. These modern hydraulic truck cranes are usually single-engine machines, with the same engine powering the undercarriage and the crane boom. THe upper is usually powered via hydraulics run through the turnable from the pump mounted on the lower. In older model designs of hydraulic truck cranes, there were two engines. One in the lower pulled the crane down to the road and ran a hydraulic pump for the outriggers and jacks. The one in the upper ran the upper through a hydraulic pump of its own. Many older operators favor the two-engine system due to leaking seals in the turnable of aging newer design cranes.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Customized SINO TRUK WANGPAI BRAND 5T truck with crane adopts SINO TRUK Wangpai 2100mm driver cab, 3900mm wheelbase, yunnei YNF40E2 160hp diesel Euro 5 engine, 9 speed manual gearbox, 9tons rear axle, 825R20 rail tires, etc.
The cargo body dimension of SINO TRUK WANGPAI 160hp 5tons truck with crane is 4300,4500×2100,2200×600(mm); while the overall dimension of the truck mounted on crane is 7330×2260,2360×3500,3600(mm). Client chooses to install CLW brand 5tons telescopic crane boom.
The specification of SINO TRUK WANGPAI 5tons truck with crane as below
| Product name | SINO TRUK WANGPAI 4*2 LHD 5tons telescopic boom mounted on truck for sale | |
| Chassis type | CDW1090HA1R5 | |
| Parameters | O1verall dimension length/width/height (mm) | 7330×2260,2360×3500,3600(mm) |
| Cargo body dimension (L*W*H)(mm) | 4300,4500×2100,2200×600 | |
| GVW(kg) | 9495 (Kg) | |
| Kerb Mass(kg) | 7450 (Kg) | |
| Rated mass(kg) | 1850 (Kg) | |
| Approach angle/ Departure angle(mm) | 24/15 (°) | |
| Front suspension/rear suspension(mm) | 1285/2145 | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | YNF40E2 |
| Displacement/Power(kw) | 3920ml/115KW/160hp | |
| Manufacturer | YUNNEI | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 3900 | |
| Tread(front/rear) | 1750/1650 (mm) | |
| Transmission | 9 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | SINO TURK WANGPAI Light duty 2100mm single row driver cab | |
| Number of spring axle(front/rear) | 11/11+99/12+9 | |
| Tire Type | 8.25R16 | |
| Front axle/rear axle | 9tons rear axle | |
| Air-condition | Choose to install | |
| Upper part(cargo van and crane boom) main parameters | ||
|
Cargo body dimension Material Side sheet thickness Bottom sheet thickness Painting Crane boom main parameters Crane boom Rotation The color of the whole truck is upon request. |
4300,4500×2100,2200×600 | |
| Carbon steel | ||
| 2mm thickness | ||
| 2mm thickness | ||
| Upon request | ||
| Choose to install CLW brand 5tons crane boom | ||
| Full hydraulic, full rotation | ||
