HOT SALE! Dongfeng T5 4*2 Euro 5 8tons telescopic crane boom mounted on truck for sale, Higher quality truck with crane
HOT SALE! Dongfeng T5 4*2 LHD 8tons telescopic crane boom mounted on truck for sale, Higher quality dongfeng 8tons telescopic truck wirh crane
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of truck mounted crane in China. With many years'experience in supplying, Chengli Special Automobile Co., Ltd. can supply Dongfeng truck mounted crane, Foton crane truck, HOWO truck with crane, ISUZU cargo truck with crane, FAW truck with crane, etc. More information, please feel free to contact with us.
Customized dongfeng T5 4*2 LHD 8tons telescopic crane boom mounted on truck adopts Dongfeng T5 T702 driver cab, yuchai 180hp diesel engine, 5100mm wheelbase, fastgear 8 speed manual gearbox, 5.5tons front axle/10tons rear axel, 300mm boom, 10.00R20 rail tires, etc.
The dimension of cargo body box is 5800,6100×2300×550,600(mm), and the overall dimension of Dongfeng T5 4*2 LHD 8tosn telescopic truck mounted with crane is 9000×2400,2500×3850,3650,3450(mm). Client choose to install CLW Brand high quality 6.3tons-8tons telescopic/knuckle crane boom.
If you're interested in our telescopic crane boom mounted on truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Wbebsite: www.trucksinchina.com
More pictures of dongfeng T5 4*2 LHD 8tons Telescopic crane boom mounted on turck as below.
customized Dongfeng T5 4*2 LHD 8t telescopic crane mounted on truck with rear hydraulic ladder for sale
The specification of Dongfeng T5 4*2 LHD 8T telescopic crane boom mounted on truck as below.
| Product name | Dongfeng T5 8tons telescopic boom mounted on truck for sale | |
| Chassis type | EQ5180GLVJ | |
| Parameters | Overall dimension length/width/height (mm) | 9000×2400,2500×3850,3650,3450 |
| Cargo body dimension (L*W*H)(mm) | 5800,6100×2300×550,600 | |
| GVW(kg) | 18000(Kg) | |
| Kerb Mass(kg) | 10600 (Kg) | |
| Rated mass(kg) | 8155 (Kg) | |
| Approach angle/ Departure angle(mm) | 26/10 (°) | |
| Front suspension/rear suspension(mm) | 1250/2650 | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type | YC6JA180-50 |
| Displacement/Power(kw) | 6870ml/132KW/180hp | |
| Manufacturer | Yuchai | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 5100 | |
| Tread(front/rear) | 1810/1860 (mm) | |
| Transmission | Fastgear 8 speed manual gearbox | |
| Braking system | Air braking | |
| Number of spring axle(front/rear) | 3/4+3 | |
| Tire Type | 10.00R20 * 6+1 | |
| Air-condition | Choose to install | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 5800,6100×2300×550,600 |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 8T 4/5sections telescopic crane boom | |
| Crane boom lifting height | 15.5m/18.5m | |
| Crane boom working radius | 13.5m/16.5m | |
| Rotation | Full hydraulic, full rotation | |
| The color of the whole truck is upon request. | ||
