JIEFANG FAW brand 4*2 LHD 180hp 8tons telescopic crane boom mounted on truck for sale, truck mounted crane for sale
JIEFANG FAW brand 4*2 LHD 180hp 8tons telescopic crane boom mounted on truck for sale, HOT SALE! FAW 8tons telescopic truck with crane
The advantages of truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
1.High quality material:Our crane boom use high strength steel HG70 which is manufactured by Chinese famous steel factory--Wu Gang. It is well known for its high strength, good plasticity, good toughness and weldability.
2.Advanced technology:Our crane boom are all utilize one-time molding process,only one soldering seam, strong bearing capacity.
3.Hexagonal boom sectionmakes the boom has better centering and anti-bending ability.
4.Advanced design methodmakes the design reliable.
5.Compact structure designmakes it take over less space.
Thetruck craneis also calledtruck mounted crane,truck with crane,crane truck,etc. The truck crane is consists of special crane truck chassis, crane, hydraulic system, operation system.etc.
The truck crane is mainly used to lift and transport the large equipment, construction material. Thecrane can rotate 360° antilockwise and clockwise or full rotate.
As a professional truck mounted crane manufacturer in China, thecrane can be knuckle boom crane and telescopic boom crane. Themax lifting weight of our crane is from 2 ton to 30 tons.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
FAW brand 4*2 LHD 8tons telescopic crane boom adopts FAW J6L one row and a half driver cab, 5000mm wheelbase, CA4DK1-18E51 180hp diesel Euro 5 engine, 8 speed gearbox, etc.
The cargo body box dimension(L*W*H): 5465×2300×600(mm), client choose high quality CLW brand 8tons or XCMG brand 8tons telescopic/knuckle crane boom mounted on FAW brand truck.
More pictures of FAW brand 4*2 LHD 8tons telescopic crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
Main technical parameters of FAW 8tons telescopic boom mounted on truck as below.
| Product name | FAW brand 4*2 LHD 8tons boom mounted on truck for sale | |
| Chassis type | CA1160 | |
| Parameters | Overall dimension length/width/height (mm) | 9000×2495×3550 |
| Cargo body dimension (L*W*H)(mm) | 5465×2300×600(mm) | |
| GVW(kg) | 15600 (Kg) | |
| Kerb Mass(kg) | 9660 (Kg) | |
| Rated mass(kg) | 5745 (Kg) | |
| Approach angle/ Departure angle(mm) | 17/10 (°) | |
| Front suspension/rear suspension(mm) | 1400/2600 | |
| Fuel Type | diesel | |
| Max Speed | 102 | |
| Engine | Type | CA4DK1-18E51 |
| Displacement/Power(kw) | 4764ml/139KW/190hp | |
| Manufacturer | DACHAI | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 5000 | |
| Tread(front/rear) | 1800/1800 (mm) | |
| Transmission | Fastgear 8 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | FAW brand one row and a half driver cab | |
| Number of spring axle(front/rear) | 7/10+3 | |
| Tire Type | 900R20 rail tires | |
| Air-condition | Original air conditioner | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 5465×2300×600(mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 8 4/5 sections telescopic crane boom | |
| Crane boom lifting height | 15.5m/18.5m | |
| Crane boom working radius | 13.5m/16.5m | |
| Rotation | Full hydraulic, full rotation | |
| The color of the whole truck is upon request. | ||
