2020s new dongfeng 4tons flatbed wrecker tow truck with 3.5T/4T/5T telescopic crane boom for sale, wrecker towing truck
2020s new dongfeng 4tons flatbed wrecker tow truck with 3.5T/4T/5T telescopic crane boom for sale, high quality and competitive price wrecker towing truck
Wrecker tow truck is also called road block removal truck, tow truck, road rescue truck, road breakdown truck, etc. This kind of wrecker tow truck is with the functions of lifting, pulling and lifting-traction, etc. mainly used for road block removal vehicles, illegal vehicles of cities, road rescue, etc.
Chengli Special Automobile Co., Ltd. is the leading manufacturer and supplier of special purpose vehicles in China. With many years’ development, We Chengli Special Autumobile Co., Ltd. could supply water tank, fuel tank, feed truck, truck with crane, dump truck, garbage truck, wrecker tow truck, lpg gas pressure vessels, refrigerated truck, vacuum truck, etc. More information, please feel free to contact with Ms. Anita.
If you're interested in our wrecker tow truck, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995
Website: www.trucksinchina.com
This dongfeng brand 4*2 LHD flatbed wrecker towing truck with telescopic crane boom, adopts dongfeng duolika single row driver cab, 3800mm wheelbase, chaochai 156 Euro 5 diesel engine, 3tons front axle/5tons rear axle, 8.25R16 rail tires, with power steering and clutch power, etc.
The length of the flatbed is 5.6m, width of the flatbed is 2.35m, adopts high quality 5mm thickness diamond plate sheet, the loading capacity of the flatbed is 5,5tons, 4tons hydraulic winch, 21m length steel rope, 3tons 2 sections rear towing arm with the traction mass of 10tons.
Client can choose 3.5tons/4tons/5tons telescopic boom mounted on this dongfeng flatbed wrecker truck( high quality China made crnae booms are selective).
More pictures of Dongfeng 4tons wrecker tow truck with 4tons telescopic crane boom as below.
HOT SALE! high quality and competitive price CLW brand 4tons wrecker tow truck
High quality and competitive price 4tons wrecker towing truck for sale
the specification of Dongfeng 4tons wrecker tow truck with 4tons telescopic crane boom manufactured by Chengli Special Automobile Co., Ltd. as below.
| Overall parameters | Product name | dongfeng 4tons wrecker tow truck for sale (CLW5091TQZD5) |
| Manufacturer | Chengli Special Automobile Co., Ltd. | |
| Product model | CLW5091TQZD5 | |
| Total mass(kgs) | 9400 | |
| Rated mass(kgs) | ||
| Curb mass(kgs) | 6800 | |
| Overall dimension (L*W*H)(mm) | 8150×2350×3300 | |
| Chassis parameters | Driver cab | dongfeng 4*2 LHD single row driver cab with 3 seats |
| Approach/departure angle(°) | 21.5/11 | |
| Front/rear suspension(mm) | 1180/2570 | |
| Axles nos. | 2 | |
| Wheelbase(mm) | 4400 | |
| Axle load(kgs) | 3400/6000 | |
| Max speed(km/h) | 103 | |
| Tire specification | 825R16*6 | |
| Steel spring | 8/10+7 | |
| Front/rear tread(mm) | 1745/1640 | |
| Engine model | CY4SK251 | |
| Fuel type | Diesel | |
| Emission standard | EuroⅤ | |
| Gearbox | 6 speed gearbox, manual | |
|
Upper part parameters
|
Flatbed dimension(L*W)(mm) | 5600*2300 |
| Rear hydraulic flapping plate Length (mm) | 1000 | |
| Total flatbed length (mm) | 5600+1000 | |
| Hydraulic winch | 4tons | |
| Operation way | Bilateral linkage operation | |
| Rear towing arm | 2.5tons loading capacity fo the rear towing arm | |
| Loading capacity of the flatbed | 4tons-5tons | |
| Wire rope | 21m length | |
| Auxiliary wheels | 2 sets | |
| Special binding belts | 4 sets | |
| Caller with alarm light | Yes | |
| Crane boom | Choose to install CLW brand 3.5T/4T telescopic crane boom |
