ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality ISUZU 4T telescopic cargo truck with crane
HOT SALE! ISUZU 700P 4*2 LHD 4tons telescopic crane boom mounted on truck, high quality and competitive price ISUZU 4T telescopic cargo truck with crane
Customized truck-mounted craneis also called crane truck, truck mounted crane, truck crane, truck with crane, etc. The truck-mounted crane is mainly used to lift and transport the constuction material, equipment or other large goods by municipal corporation, mining engineering department, plant department,etc.
As a professional truck-mounted crane manufacturer in China, the truck-mounted crane for sale is from 2 ton to 32 ton. The drive type of our truck mounted crane are 4x2, 6x2, 6x4,8x4,etc. The crane we produce are telescopic boom truck mounted crane, knuckle boom crane.Also, Our crane trucks are 360 degree roatate. It is with high quality, long life, high speed, etc.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
ISUZU 700P 4T truck with crane adopts ISUZU brand 700P 4*2 LHD truck chassis, 4475mm wheelbase, ISUZU MLD 6 speed manual gearbox, ISUZU 4HK1-TCG40 190hp Euro 4 diesel engine, 4tons front axle/7tons rear axle, 8.25-16/8.25R15 tires, ISUZU 700P single row luxurious driver cab with power steering and air conditioner, etc.
The overall dimension (L*W*H) of ISUZU 4T telescopic crane boom mounted on truck is 7950×2307×3100(mm), and the cargo body box dimension (L*W*H): 5360×2150×450(mm). Client chooses to install CLW Brand high quality 4tons telescopic /knuckle crane boom.
HOT SALE! ISUZU Brand 700P 4tons telescopic crane boom mounted on truck
high quality and competitive price ISUZU 4tons telescopic cargo truck with crane for sale
The specification of ISUZU brand 4*2 700P 4tons telescopic crane boom mounted on truck as below.
| Product name | ISUZU 4*2 LHD 4T telescopic crane mounted on truck for sale | |
| Chassis type | QL11009MARY | |
| Parameters | Overall dimension length/width/height (mm) | 7950×2307×3100(mm |
| Cargo body dimension (L*W*H)(mm) | 5360×2150×450 | |
| GVW(kg) | 10000(Kg) | |
| Kerb Mass(kg) | 5150 (Kg) | |
| Rated mass(kg) | 4655(Kg) | |
| Approach angle/ Departure angle(mm) | 20/10 (°) | |
| Front suspension/rear suspension(mm) | 1110/2365 (mm) | |
| Fuel Type | diesel | |
| Max Speed | 110 | |
| Engine | Type | 4HK1-TCG40 |
| Displacement/Power(kw) | 5193ml/139KW/190hp | |
| Manufacturer | Isuzu | |
| Chassis | Drive Type | 4×2 |
| Wheelbase(mm) | 4475 | |
| Tread(front/rear) | 1680/1650 (mm) | |
| Transmission | ISUZU MLD 6 speed gearbox, manual | |
| Braking system | Air braking | |
| Cab | ISUZU brand 700P single row driver cab | |
| Number of spring axle(front/rear) | 8/10+6 | |
| Tire Type | 8.25-16/8.25R15 tires | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 5360×2150×450(mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 4tons 4sections telescopic crane boom | |
| Lifting height | 13m | |
| Working radius | 11m | |
| Aerial operation seat | Yes | |
| Hydraulic operation | Yes, full hydraulic operation | |
| Full rotation | Yes, full rotation | |
| The color of the whole truck is upon request. | ||
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Chengli Special Automobile Co., Ltd. is the leading manufacturer of truck with crane, truck mounted crane, dump truck with crane, cargo truck with crane, telescopic crane mounted on truck, etc. With many years’ experience in manufacturing, Chengli Special Automobile Co., Ltd. could manufacture and supply 4*2 small truck with crane, 4*4 truck with crane, 6*2 dump truck with crane, 6*4 cargo truck with crane, 8*4 crane monted on truck, etc. And the CLW brand cranes are from 2.5ton to 20 ton, and much bigger for different trucks. Chengli Special Automobile Co., Ltd. coulkd design and produce the trucks according to customers’ requirements. More information, please feel free to contact with us.
