Customized best price SINO TRUK HOWO 8*4 LHD 14tons knuckle truck with crane for sale, HOWO cargo truck with crane
Customized best price SINO TRUK HOWO 8*4 LHD 14tons knuckle truck with crane for sale, HOT SALE! HOWO 371hp diesel 14tons-16tons knuckle crane boom mounted on truck for sale
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
SINO TRUK HOWO 8*4 LHD knucle crane boom mounted on truck, adopts SINO TRUK HOWO 8*4 LHD truck chassis, HW76 driver cab, 1800+4600+1350mm wheelbase, HW19710 10 speed manual gearbox, HW70 PTO, HF9T front axle/HC16t rear axles, 12.00R20 rail tires,etc.
The overall dimension(L*W*H) of SINO TRUK HOWO 8*4 LHD 14T-16T knuckle truck with crane is 11990×2498×3990(mm); while the cargo box body dimension(L*W*H): 8000×2390×500,400,400(mm). Client chooses to install CLW Brand high quality 14tons/16tons telescopic/knuckle crane boom.
More pictures of SINO TRUK HOWO 14T knuckle crane boom mounted on truck as below.
high quality and competitive price SINO TRUK HOWO 14tons truck with crane for sale
The specification of SINO TRUK HOWO 14Tons knuckle crane boom mounted on truck manufactured by Chengli Special Automobile Co., Ltd. as below.
| Product name | SINO TRUK HOWO 8*4 LHD 14tons knuckle truck with crane for sale (CLW5310JSQZ4) | |
| Chassis type | ZZ1317N4667W | |
| Parameters | Overall dimension length/width/height (mm) | 11990×2498×3990 |
| Cargo body dimension (L*W*H)(mm) | ,8000×2390×500,400,400 | |
| GVW(kg) | 31000 (Kg) | |
| Kerb Mass(kg) | 11880,11945 (Kg) | |
| Rated mass(kg) | 5255(Kg) | |
| Approach angle/ Departure angle(mm) | 16/14 (°) | |
| Front suspension/rear suspension(mm) | 1500/2715, | |
| Fuel Type | diesel | |
| Max Speed | 102 | |
| Engine | Type | WD615.47 |
| Displacement/Power(kw) | 9726ml/273KW/371hp | |
| Manufacturer | SINO TRUK HOWO | |
| Chassis | Drive Type | 8*4 |
| Wheelbase(mm) | 1800+4600+1350mm | |
| Tread(front/rear) | 1960/1855 (mm) | |
| Transmission | HW19710 10 speed manual gearbox | |
| Braking system | Air braking | |
| Cab | HW76 driver cab | |
| Number of spring axle(front/rear) | 4/4/- | |
| Tire Type | 12.00R20 rail tires | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | ,8000×2390×500,400,400 |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 14T 5 sections knuckle crane boom | |
| The color of the whole truck is upon request. | ||
