HOT SALE! Dayun 6*4 10Tons-12tons telescopic crane boom mounted on truck for sale, cheaper 10-12T cargo truck with crane
HOT SALE! Dayun brand 6*4 10Tons-12tons telescopic crane boom mounted on truck for sale,Customized cheaper price 10T-12T telescopic cargo truck with crane
CLW truck mounted crane is one of our main mature products which is also named hydraulic truck crane, mobile crane, truck mounted crane, lorry-mounted crane, lorry crane, truck with loading crane, truck cargo crane and so on. It is widely used in various loading and unloading, installation and lifting, especially in the field of outdoor lifting, salvage operation and other narrow places such as station, port, warehouse and construction site.
Product Notes of CLW brand truck mounted crane manufactured by Chengli Special Automobile Co., Ltd. as below.
· Optional: from 2 ton to 200 ton lifting capacity crane truck
· Optional: straight arm and floding arm truck crane with or without remote control
· Optional: different famous crane brand: HIAB, Shimei, Zoomlion, Sany, Chengli balong, etc.
· Optional: different famous chassis brand: Dongfeng, FAW, Foton, Sinotruk, Syter, Shaanxi, T-king, Dayun, Yuejin, JMC, JAC, etc.
· Factory direct sale, low price and good quality.
If you're interested in our truck with crane, please send email to truck0011@163.com or talk to Anita by Whatsapp/Wechat/Mob.: +86 13329899995.
Website: www.trucksinchina.com
Customized DAYUN brand 6*4 10tons-12tons telescopic truck with crane, adopts dayun fengjing 2150mm single row 4300+1300mm wheelbase, yuchai 180hp/220hp diesel Euro 5 engine, 8 speed gearbox, 153 front/rear axle, 10.00R20 rail tires, etc.
The overall dimension of dayun 6*4 10tons-12tons telescopic crane boom mounted on truck is 10650×2550×3650,3850(mm); while the cargo body box dimension(L*W*H) is 6.6*2.4*0.6(mm). Client choose to install CLW Brand/XCMG brand 10tons/12tons telescopic crane boom.
The specification of Dayun 10tons-12tons telescopic crane boom mounted on truck as below.
| Product name | DAYUN brand 6*4 10tons telescopic crane boom mounted on truck for sale | |
| Chassis type | DYQ1253D5CA | |
| Parameters | Overall dimension length/width/height (mm) | 10650×2550×3650,3850 |
| Cargo body dimension (L*W*H)(mm) | 6600×2300,2400×550,600 | |
| GVW(kg) | 24500(Kg) | |
| Kerb Mass(kg) | 13500 (Kg) | |
| Rated mass(kg) | 10805(Kg) | |
| Approach angle/ Departure angle(mm) | 20/14 (°) | |
| Front suspension/rear suspension(mm) | 1450/3050 | |
| Fuel Type | diesel | |
| Max Speed | 90 | |
| Engine | Type |
YC6JA180-50 YC6JA220-50 |
| Displacement |
6870ml; 6870ml; |
|
| Rated power |
132KW; 162KW |
|
| Manufacturer | Yuchai | |
| Chassis | Drive Type | 6*4 LHD |
| Wheelbase(mm) | 4300+1300MM | |
| Tread(front/rear) | 1965/1865 (mm) | |
| Transmission | 8 speed gearbox, manual | |
| Braking system | Air braking | |
| Number of spring axle(front/rear) | 3/7+-/8+6 | |
| Tire Type | 10.00R20 | |
| Air-condition | Choose to install | |
| Upper part(cargo van and crane boom) main parameters | ||
| Upper body | Cargo body dimension | 6600×2300,2400×550,600 (mm) |
| Material | Carbon steel | |
| Side sheet thickness | 2mm thickness | |
| Bottom sheet thickness | 2mm thickness | |
| Painting | Upon request | |
| Crane boom main parameters | ||
| Crane boom | Choose to install CLW brand 10-12tons telescopic crane boom | |
| Rotation | Full hydraulic, full rotation | |
| The color of the whole truck is upon request. | ||
